Omron G2RV-ST501 AC/DC24
Omron G2RV-ST501 AC/DC24 SPDT relay with 24 VAC/DC coil, push-in terminals, LED and mechanical indicator, and 6 A rated load.
The Omron G2RV-ST501 AC/DC24 is a general-purpose electromechanical relay with SPDT contacts and dual LED and mechanical indicators for status visibility. Designed for reliable switching in industrial applications, it supports both AC and DC coil operation at 24 V.
It features push-in terminals for easy installation, operates within a temperature range of –40 to +55°C, and complies with RoHS standards. The relay handles a rated load of 6 A at 250 VAC or 30 VDC, with maximum switching capacity of 440 VAC, 125 VDC, and 6 A. Power consumption is approximately 0.5 VA AC or 300 mW DC, with maximum switching power of 1,500 VA and 180 W resistive, or 500 VA and 60 W inductive.
| Coil voltage | 24 VAC/DC |
|---|---|
| Contact arrangement | SPDT |
| Indicator | LED & Mechanical |
| Max. switching current | 6A |
| Max. switching power (inductive) | 500 VA, 60 W |
| Max. switching power(resistive) | 1,500 VA, 180 W |
| Max. switching voltage | 440 VAC, 125 VDC |
| Operating Temperature | –40 to +55°C |
| Power consumption | Approx. 0.5 VA, Approx. 300 mW DC |
| Rated load (resistive) | 6 A @ 250 VAC, 6 A @ 30 VDC |
| RoHS Compliant | Yes |
| Terminal | Push-in terminals |
Frequently Asked Questions
How do I get pricing for G2RV-ST501 AC/DC24?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the G2RV-ST501 AC/DC24?
G2RV-ST501 AC/DC24 is a Omron part. KKM Solutions sources Omron components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of G2RV-ST501 AC/DC24?
Key specifications include Coil voltage: 24 VAC/DC; Contact arrangement: SPDT; Indicator: LED & Mechanical; Max. switching current: 6A. The full specification table on this page lists every published attribute for this part.
How quickly can G2RV-ST501 AC/DC24 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
