Omron DRT1-0D16T-1 | Omron DeviceNet Output Module, 16-Point PNP Transistor, 24 VDC

Description The Omron DRT1-0D16T-1 is a DeviceNet output module designed for efficient and reliable distributed I/O control in industrial automation systems. It provides sixteen transistor outputs (PNP type), enabling fast and stable signal transmission to actuators, relays, and control devices over a DeviceNet network. Technical Specifications Condition New/Never Used Surplus Brand Omron Category Remote I/O Modules Part Number DRT1-0D16T-1 Subcategory Output Module Series DRT1 Series Network Type DeviceNet Output Type Transistor (PNP, sourcing) Number of Outputs 16 Rated Output Voltage 24 VDC Rated Output Current 0.5 A per point (max.) Isolation Type Photocoupler isolation between outputs and logic circuit Power Supply Voltage 24 VDC ±10% Output Protection Short-circuit and overload protection Status Indicators Power, communication, and output LEDs Communication Speed 125 kbps, 250 kbps, 500 kbps (auto-detect) Node Address Setting Rotary switch (0–63) Mounting Type DIN rail or panel mount Connection Type Removable terminal block or DeviceNet connector Operating Temperature 0°C to +55°C Storage Temperature –25°C to +70°C Enclosure Protection IP20 (for control panel installation) Compliance CE, UL, RoHS Application Distributed control of outputs in DeviceNet automation systems Weight Approx. 250 g Information About DRT1-0D16T-1 The DRT1-0D16T-1 is part of Omron’s DRT1 series of intelligent distributed I/O modules engineered for use with the DeviceNet communication protocol. This output module offers 16 transistor outputs, each capable of driving loads such as solenoids and indicator lamps, with PNP sourcing logic for positive switching. It integrates seamlessly with Omron PLCs and other networked controllers, supporting real-time monitoring, diagnostic feedback, and fault detection. The unit’s compact housing, DIN-rail mounting capability, and standard DeviceNet connectors allow for flexible installation and simplified wiring in factory automation systems. Key Features: 16 Transistor Outputs: Provides sixteen PNP outputs for driving various field devices. DeviceNet Compatibility: Fully compliant with Omron’s DeviceNet network architecture for distributed control. High-Speed Response: Transistor outputs ensure fast switching for real-time operation. Compact Modular Design: Optimized for panel or machine-mount installation in limited spaces. Integrated Diagnostics: Built-in LED indicators display power, network, and output status. Easy Configuration: Supports node address setting via rotary switches for quick setup. Durable Construction: Industrial-grade housing designed for vibration and electrical noise resistance. Wide Application Use: Ideal for controlling solenoids, pilot lamps, and relays in automated machinery. The DRT1-0D16T-1 delivers the reliability and precision required for distributed output control in DeviceNet-based industrial automation systems.
