110670.00 Leeson 1/2 hp 1800 RPM 208-230/460V 56C Frame (Rigid Base) TENV 3-Phase Brake Motor
KKM Solutions is an independent parts distributor, not an authorized Leeson dealer — how we source.
110670.00 Leeson 1/2 hp 1800 RPM 208-230/460V 56C Frame (Rigid Base) TENV 3-Phase Brake Motor
Overview
Part number 110670.00 from Leeson, listed in Motor Brakes & Accessories. Specifications on file: Duty Continuous; Enclosure Type TENV; Frame 56C; Frame Material Rolled Steel. KKM Solutions quotes this part with pricing and availability confirmed per order.
110670.00 Leeson 1/2 hp 1800 RPM 208-230/460V 56C Frame (Rigid Base) TENV 3-Phase Brake Motor
This Leeson 3-phase brake motor delivers reliable 1/2 horsepower performance at 1800 RPM, designed for industrial applications requiring controlled stopping. It is a direct replacement motor featuring a rigid base and a totally-enclosed non-ventilated (TENV) design for enhanced durability in demanding environments.
Key Specifications
Horsepower: 1/2 hp
RPM: 1800
Voltage: 208-230/460 V
Amperage: 2.0-1.8/0.9 A
Enclosure: Totally-Enclosed Non-Ventilated (TENV)
Frame / Diameter: NEMA 56C Frame
Shaft Dimensions: 5/8" Diameter x 1 5/8" Length
Rotation: Reversible
Bearings: Ball Bearings
Product Features & Fitment
This brake motor features a C-face mount with the brake engaged when power is off, providing controlled stopping for safety and precision. The rigid base mounting includes bolt holes spaced 3 3/4" on center across the shaft for straightforward installation. Wiring diagrams are provided on the motor nameplate to assist with proper electrical connections.
Specifications
| Duty | Continuous |
|---|---|
| Enclosure Type | TENV |
| Frame | 56C |
| Frame Material | Rolled Steel |
| Frequency | 60 Hz |
| Full Load Amps | 2.0-1.8/0.90 |
| Horsepower | 1/2 HP |
| Mounting | C-Face / Rigid |
| Phase | 3 |
| Power | 1/2 HP |
| Speed | 1800 RPM |
| Voltage rating | 460 V |
Product details
| Manufacturer | Leeson |
|---|---|
| Manufacturer part number | 110670.00 |
| Product category | Motor Brakes & Accessories |
| Published specifications | 12 attributes listed |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 110670.00 cost?
110670.00 is listed at CA$1,535.56 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email orderdesk@kkmsolutions.com for a volume quote.
Who manufactures the 110670.00?
110670.00 is a Leeson part, sourced to the exact manufacturer specification.
What is the lifecycle status of 110670.00?
No published lifecycle status is on file for 110670.00. Leeson lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of 110670.00?
Key specifications include Duty: Continuous; Enclosure Type: TENV; Frame: 56C; Frame Material: Rolled Steel. The full specification table on this page lists every published attribute for this part.
How quickly can 110670.00 ship?
Lead time is quoted per part and confirmed on your quote.
