Kimray EYTS6NC
Kimray EYTS6NC - industrial components - Weight: 92.31 lbs; Connection type: 150 RF; Body material: Steel.
This listing covers the Kimray EYTS6NC, a part number in the industrial components category. The manufacturer's published data for this part number specifies Weight: 92.31 lbs and Connection type: 150 RF.
Published specifications for this part include Body material: Steel; Operation: Pneumatic; Connection Size: 3 "; Trim / Material: Stainless Steel; Body style: Through Body; Max Working Pressure: 285 psig; NACE MR0175: NACE MR0175 Certificate included; Trim Size: 2.25 "; Trim Type: Linear (Nominal); Leakage Class: Class VI; Process Fluid: Liquid and Gas; Face-to-Face Length: 12.188 ". See the Specifications tab on this page for the full technical table.
| Actuator Crack Open Pressure | 10 psig |
|---|---|
| Actuator Full Open Pressure | 35 psig |
| Actuator Spring Nominal Pressure | 35 psig |
| Body material | Steel |
| Body style | Through Body |
| Cf | 0.79 |
| Connection Size | 3 " |
| Connection type | 150 RF |
| Face-to-Face Length | 12.188 " |
| Fail Position | Closed |
| Leakage Class | Class VI |
| Max Cv | 43.8 |
| Max Differential Pressure | 285 psi |
| Max Supply Gas Pressure | 45 psig |
| Max Working Pressure | 285 psig |
| NACE MR0175 | NACE MR0175 Certificate included |
| Operation | Pneumatic |
| Process Fluid | Liquid and Gas |
| Trim / Material | Stainless Steel |
| Trim Size | 2.25 " |
| Trim Type | Linear (Nominal) |
| Weight | 92.31 lbs |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for EYTS6NC?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EYTS6NC?
EYTS6NC is a Kimray part. KKM Solutions sources Kimray components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is EYTS6NC discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for EYTS6NC — check Kimray's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of EYTS6NC?
Key specifications include Actuator Crack Open Pressure: 10 psig; Actuator Full Open Pressure: 35 psig; Actuator Spring Nominal Pressure: 35 psig; Body material: Steel. The full specification table on this page lists every published attribute for this part.
How quickly can EYTS6NC ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
