EYMS6V Kimray
KKM Solutions is an independent parts distributor, not an authorized Kimray dealer — how we source.
Kimray EYMS6V - industrial components - Weight: 140 lbs; Connection type: 150 RF; Body material: Cast Ductile.
Overview
Part number EYMS6V from Kimray. Specifications on file: Actuator Crack Open Pressure 10 psig; Actuator Full Open Pressure 35 psig; Actuator Spring Nominal Pressure 35 psig; Body material Cast Ductile. KKM Solutions quotes this part with pricing and availability confirmed per order.
This listing covers the Kimray EYMS6V, a part number in the industrial components category. The manufacturer's published data for this part number specifies Weight: 140 lbs and Connection type: 150 RF.
The specification set recorded for this part number covers Body material: Cast Ductile; Operation: Pneumatic; Connection Size: 4 "; Trim / Material: Stainless Steel; Body style: Through Body; Max Working Pressure: 250 psig; NACE MR0175: NACE MR0175 Compliant; Trim Size: 3 "; Trim Type: Linear (Nominal); Leakage Class: Class VI; Process Fluid: Liquid and Gas; Face-to-Face Length: 15 ". See the Specifications tab on this page for the full technical table.
Specifications
| Actuator Crack Open Pressure | 10 psig |
|---|---|
| Actuator Full Open Pressure | 35 psig |
| Actuator Spring Nominal Pressure | 35 psig |
| Body material | Cast Ductile |
| Body style | Through Body |
| Cf | 0.79 |
| Connection Size | 4 " |
| Connection type | 150 RF |
| Elastomer | FKM |
| Face-to-Face Length | 15 " |
| Fail Position | Closed |
| Leakage Class | Class VI |
| Max Cv | 70.1 |
| Max Differential Pressure | 250 psi |
| Max Supply Gas Pressure | 45 psig |
| Max Working Pressure | 250 psig |
| NACE MR0175 | NACE MR0175 Compliant |
| Operation | Pneumatic |
| Process Fluid | Liquid and Gas |
| Trim / Material | Stainless Steel |
| Trim Size | 3 " |
| Trim Type | Linear (Nominal) |
| Weight | 140 lbs |
Product details
| Manufacturer | Kimray |
|---|---|
| Manufacturer part number | EYMS6V |
| Published specifications | 23 attributes listed |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for EYMS6V?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EYMS6V?
EYMS6V is made by Kimray. KKM Solutions is an independent distributor, not an authorized Kimray dealer: we source the exact Kimray part number EYMS6V, and the quote confirms condition and lead time before you order.
Is the EYMS6V new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the EYMS6V, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of EYMS6V?
No published lifecycle status is on file for EYMS6V. Kimray lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of EYMS6V?
Key specifications include Actuator Crack Open Pressure: 10 psig; Actuator Full Open Pressure: 35 psig; Actuator Spring Nominal Pressure: 35 psig; Body material: Cast Ductile. The full specification table on this page lists every published attribute for this part.
What thread or connection does EYMS6V use?
Per the published specification for EYMS6V: Connection Size: 4 "; Connection type: 150 RF. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How much does EYMS6V weigh?
Per the published specification for EYMS6V: Weight: 140 lbs. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can EYMS6V ship?
Lead time for EYMS6V is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
