Kimray ACV5
Kimray ACV5 - industrial components - Connection type: Female NPT; Body material: Cast Ductile; Operation: Pneumatic.
Kimray ACV5 is an industrial components catalog item from Kimray. The manufacturer's published data for this part number specifies Connection type: Female NPT and Body material: Cast Ductile.
The specification set recorded for this part number covers Operation: Pneumatic; Connection Size: 1 "; Body style: Through Body; Catalog Page: 06:80.1; Max Working Pressure: 300 psig; NACE MR0175: Option Available for NACE MR0175 compliance or certification; Trim Size: 0.5 "; Trim Type: Equal Percentage; Leakage Class: Class VI; Process Fluid: Gas; Pilot Type: Vent; Min Set Point Pressure: 10 psig. See the Specifications tab on this page for the full technical table.
| Body material | Cast Ductile |
|---|---|
| Body style | Through Body |
| Catalog Page | 06:80.1 |
| Cf | 0.75 |
| Connection Size | 1 " |
| Connection type | Female NPT |
| Face-to-Face Length | 4.375 " |
| Leakage Class | Class VI |
| Max Cv | 5 |
| Max Set Point Pressure | 300 psig |
| Max Working Pressure | 300 psig |
| Min Set Point Pressure | 10 psig |
| NACE MR0175 | Option Available for NACE MR0175 compliance or certification |
| Operation | Pneumatic |
| Pilot Type | Vent |
| Process Fluid | Gas |
| Trim Size | 0.5 " |
| Trim Type | Equal Percentage |
