Kacon 730-1QB-220VAC

KACON is a Korean manufacturer for a full line of switches and control components. They work with many international brands and are sold through key distributors around the world. Their products are readily available from Illinois and they have very competitive pricing. Features Include: Configuration: SPST NO(1a) Material: Silver alloy Rated current: 30A Rated Max. Resistive Load: 30A at 30VDC/277VAC Max. Switching Voltage: DC900W/AC8, 310VA, DC750W/AC5, 500VA Min. Switching requirement: 100mA 5VDC Voltage range: 6VDC to 110VDC, 6VAC to 240VAC Power consumption: DC: approx. 1.9W, 6-48VAC: 1.7-1.9VA, 100/120VAC: 1.9-2.7VA, 200/240VAC: 1.8-2.6VA Minimum operating voltage: 80% of the rated coil voltage Dropout voltage: DC Coil: 10% of rated voltage, AC Coil: 30% of rated voltage Operating Time: 30ms max. at rated coil voltage Ambient temperature: -10 ~ +60°C(-14°F~140°F) at nonfreezing Weight: TB Type: 90g (3.2oz), QB Type: 120g (4.2oz) Supplied by KKM Solutions as part of our relays range. Contact orderdesk@kkmsolutions.com for pricing and availability.
