IPTCI SUCNPFL207-35MM — Flange Bearing Units
IPTCI SUCNPFL207-35MM - Flange Bearing Units - Series: SUCNPFL Stainless Steel Set Screw Locking 2-Bolt Nickel Plated Flange; Housing material: Nickel Plated; Overall Width: 44 mm.
In our catalog, the SUCNPFL207-35MM from IPTCI is listed under the Flange Bearing Units category. The manufacturer's published data for this part number specifies Series: SUCNPFL Stainless Steel Set Screw Locking 2-Bolt Nickel Plated Flange and Housing material: Nickel Plated.
The specification set recorded for this part number covers Overall Width: 44 mm; Dynamic Load Rating: 4930; Static Load Rating: 2780; Operating temperature - max: 250 °; Bore Diameter: 35 mm; Industry Standard: AFBMA; Bearing Material: Stainless Steel; Closure Type: Dual Seals (B-Type); Grease Type: H1 Food Grade Grease; Mounting Type: Two (2) Bolt, Two (2) Bolt Flange; Locking Type: Set Screw; Length Through Bore: 42.9 mm. See the Specifications tab on this page for the full technical table.
| Bearing Material | Stainless Steel |
|---|---|
| Bore Diameter | 35 mm |
| Closure Type | Dual Seals (B-Type) |
| Duty Type | Standard |
| Dynamic Load Rating | 4930 |
| Grease Type | H1 Food Grade Grease |
| Housing material | Nickel Plated |
| Industry Standard | AFBMA |
| Length Through Bore | 42.9 mm |
| Locking Type | Set Screw |
| Mounting Type | Two (2) Bolt, Two (2) Bolt Flange |
| Operating temperature - max | 250 ° |
| Overall Width | 44 mm |
| Relubricatable | Relubricatable |
| Series | SUCNPFL Stainless Steel Set Screw Locking 2-Bolt Nickel Plated Flange |
| Static Load Rating | 2780 |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for SUCNPFL207-35MM?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the SUCNPFL207-35MM?
SUCNPFL207-35MM is a IPTCI part. KKM Solutions sources IPTCI components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is SUCNPFL207-35MM discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for SUCNPFL207-35MM — check IPTCI's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of SUCNPFL207-35MM?
Key specifications include Bearing Material: Stainless Steel; Bore Diameter: 35 mm; Closure Type: Dual Seals (B-Type); Duty Type: Standard. The full specification table on this page lists every published attribute for this part.
How quickly can SUCNPFL207-35MM ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
