igus MAT9850103 — Motor Cable

Igus MAT9850103 8/4C 16/2P 8-Pin Female Intercontec Connector PUR B&R i8CMxxx.12-5 Motor Cable Allowable Ampacity for Igus MAT9850103 8/4C 16/2P 8-Pin Female Intercontec Connector PUR B&R i8CMxxx.12-5 Motor Cable : 100 Amps Also Known as: Motor Connector, Igus Intercontec Connector , IGUS, Intercontec Connector, IGUS Motor Connector, B&R Connector Construction: • Conductor: Fine-wire stranded conductor in especially bending-resistant version consisting of bare copper wires (according to DIN EN 60228) • Conductor Insulation: Mechanically high-quality, especially low-capacitance TPE mixture • Conductor Construction: Power cores with control pair elements stranded with elements for high tensile stresses • Conductor Identification: Energy conductor: Cores black with white numerals, one core green-yellow. 1.Core: U / L1 / C / L+ 2.Core: V / L2 3.Core: W / L3 / L- 2 Signal pairs: Cores black with white numerals. 1. Signal pair: 5 2. Signal pair: 6 3. Signal pair: 7 4. Signal pair: 8 • Overall shield: Bending-resistant braiding made of tinned copper wires. Coverage approx. 55% linear, approx. 80% optical. • Jacket Color: Pastel orange (similar to RAL 2003) • Outer jacket: Low-adhesion, oil-resistant mixture on the basis of PVC, adapted to suit the requirements in e-chains (following DIN EN50363-4-1) Properties and Approvals: • UV resistance: Medium • Oil Resistance: Oil-resistant according to DIN EN 50363-10-2 • Offshore: MUD-resistant following NEK 606 - status 2009 • Flame retardant: According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 • Silicone-free: Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). • Halogen-free: Following EN 60754 • UL/CSA AWM: See data sheet for details • NFPA 79: Following NFPA 79-2012 chapter 12.9 • DNV: Certified according to DNV Type Testing – Certificate No.: 61 935-14 HH • EAC : Certified according to No. TC RU C-DE.ME77.B.01255 • CTP: Certified to no. C-DE.PB49.B.00420 • Lead free: Following 2011/65/EU (RoHS-II) • CEI: Following CEI 20-35 • Clean room: According to ISO Class 1. Outer jacket material complies with CF27.07.05.02.01.D, tested by IPA according to standard 14644-1 • DESINA: According to VDW, DESINA standardization • CE Guideline: Following 2014/35/EU Specification: AWG size: 8 Number of Conductor: 4 AWG size: 16 Number of Pair: 2 Conductor: Bare Copper Insulation: TPE Jacket: PUR Outer Diameter: 0.89 inch Copper Index: 387.1 lbs/mft Voltage: 1000 V Weight: 596.0 lbs/mft Part Number: MAT9850103
