igus MAT9560042 — Motor Cable
igus Igus MAT9560042 12/4C 16/1P Round Plug Socket Connector PVC Control Techniques PB B B A A Pre-Assembled Servo Motor Cable 1 / 1 FT
Overview
Igus MAT9560042 12/4C 16/1P Round Plug Socket Connector PVC Control Techniques PB B B A A Pre-Assembled Servo Motor Cable Allowable Ampacity for Igus MAT9560042 12/4C 16/1P Round Plug Socket Connector PVC Control Techniques PB B B A A Pre-Assembled Servo Motor Cable : 100 Amps Also Known as: Motor Connector, Igus Motor Connector, IGUS, Igus Pre-Assembled Connector, IGUS Connector, Servo Motor Connector Construction: • Conductor: Fine-wire stranded conductor in especially bending-resistant version consisting of bare copper wires (according to DIN EN 60228) • Conductor Insulation: Mechanically high-quality, especially low-capacitance TPE mixture • Conductor Construction: Power cores with control pair elements stranded with elements for high tensile stresses • Conductor Identification: Energy conductor: Cores black with white numerals, one core green-yellow. 1.Core: U / L1 / C / L+ 2.Core: V / L2 3.Core: W / L3 / L- 1 Signal pair: Cores black with white numerals. 1. Control core: 4 2. Control core: 5 • Overall shield: Extremely bending-resistant braiding made of tinned copper wires. Coverage approx. 70% linear, approx. 90% optical. • Jacket Color: Moss green (similar to RAL 6005) • Outer jacket: Low-adhesion, oil-resistant mixture on the basis of PVC, adapted to suit the requirements in e-chains (following DIN EN50363-4-1) Properties and Approvals: • UV resistance: Medium • Oil Resistance: Oil-resistant according to DIN EN 50363-4-1 • Flame retardant: According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 • Silicone-free: Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). • UL/CSA AWM: See data sheet for details • NFPA 79: Following NFPA 79-2012 chapter 12.9 • EAC : Certified to no. TC RU C-DE. ME77.B.02324 • CTP: Certified to no. C-DE.PB49.B.00420 • Lead free: Following 2011/65/EU (RoHS-II) • CEI: Following CEI 20-35 • Clean room: According to ISO Class 2. Outer jacket material complies with CF5.10.07, tested by IPA according to standard 14644-1 • CE Guideline: Following 2014/35/EU Specification: AWG size: 12 Number of Conductor: 4 AWG size: 16 Number of Conductor: 1 Conductor: Bare Copper Insulation: TPE Jacket: PVC Outer Diameter: 0.63 inch Copper Index: 172.0 lbs/mft Voltage: 1000 V Weight: 272.8 lbs/mft Part Number: MAT9560042
Specifications
| Piece | 1 |
|---|---|
| Size | 1 FT |
| Tag | Ctrl 8 |
| Weight | 286.44 lb |
Product details
| Manufacturer | igus |
|---|---|
| Manufacturer part number | MAT9560042 |
| KKM catalog reference | IGUS-MAT9560042 |
| Product category | Motor Cable |
| Published specifications | 4 attributes listed |
| Related part numbers | 18 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does MAT9560042 cost?
MAT9560042 is listed at CA$174.74 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the MAT9560042?
MAT9560042 is a igus part. KKM Solutions sources igus components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is MAT9560042 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for MAT9560042 — check igus's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of MAT9560042?
Key specifications include Piece: 1; Size: 1 FT; Tag: Ctrl 8; Weight: 286.44 lb. The full specification table on this page lists every published attribute for this part.
How quickly can MAT9560042 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
Variants & Related Part Numbers
Other igus part numbers in this family:
- MAT9560001 — igus readycable® motor cable suitable for Control Techniques PS B G A…
- MAT9560018 — igus readycable® motor cable suitable for Control Techniques PS B E F…
- MAT9560020 — igus readycable® motor cable suitable for Control Techniques PS B A B…
- MAT9560021 — igus readycable® motor cable suitable for Control Techniques PS B B B…
- MAT9560022 — igus readycable® motor cable suitable for Control Techniques PS B C B…
- MAT9560023 — igus readycable® motor cable suitable for Control Techniques PS B D B…
- MAT9560024 — igus readycable® motor cable suitable for Control Techniques PS B E B…
- MAT9560040 — igus Igus MAT9560040 16/4C 16/1P Round Plug Socket Connector PVC Control Techniques…
- MAT9560043 — igus Igus MAT9560043 16/4C 16/1P Round Plug Socket Connector PVC Control Techniques…
- MAT9560058 — igus Igus MAT9560058 16/4C 16/1P Unidrive Round Plug Socket PVC Control Techniques…
- MAT9560060 — igus Igus MAT9560060 12/4C 16/1P Unidrive Round Plug Socket PVC Control Techniques…
- MAT9560064 — igus Igus MAT9560064 16/4C 16/1P Unidrive Round Plug Socket PVC Control Techniques…
- MAT9560100 — igus readycable® encoder cable suitable for Control Techniques SS B A H…
- MAT9560101 — igus readycable® encoder cable suitable for Control Techniques SS B A H…
- MAT9560921 — igus Igus MAT9560921 8 AWG 4C 90 Degree Coupling Pin A Connector…
- MAT9561411 — igus readycable® motor cable suitable for SEW 0199 5588, extension cable (Amphenol),…
- MAT9561517 — igus Igus MAT9561517 16 AWG 4C Round Plug Socket A / Coupling…
- MAT9562501 — igus readycable® motor cable, suitable for Delta, A2P-1-.75-xx, base cable iguPUR 15…
