SF223A IFM Flow sensor for connection to an evaluation unit
KKM Solutions is an independent parts distributor, not an authorized IFM dealer — how we source.
IFM SF223A - Flow sensor for connection to an evaluation unit - Material: ceramics (99.7 % Al2O3); Ambient temperature: -20...70.
Overview
Part number SF223A from IFM, listed in Flow Sensors & Meters. Specifications on file: Ambient temperature -20...70; Approval DMT 03 ATEX E091; IECEx BVS 06.0007; ATEX marking II 2G Ex ia IIC T4 Gb; Connection to control monitor VS2000 Exi (PTB 01 ATEX 2075). KKM Solutions quotes this part with pricing and availability confirmed per order.
This listing covers the IFM SF223A, a part number in the Flow sensor for connection to an evaluation unit category. The manufacturer's published data for this part number specifies Material: ceramics (99.7 % Al2O3).
For applications in hazardous areas; Reliable monitoring of aggressive liquids in pipes; For connection to an evaluation unit; Ceramic materials for contact with the medium; Robust design for use in harsh industrial environments
Published specifications for this part include Ambient temperature: -20...70; Approval: DMT 03 ATEX E091; IECEx BVS 06.0007; Product type: Flow sensor for connection to an evaluation unit; Cable: 6 m, TPE-S; Maximum cable length: 100 m; 5 x 0.34 mm²; Response time: 2...20; Process Connection: threaded connection G 1/4 external thread; Medium temperature: 5...70; Housing: tubular; Media: Liquids; aggressive media; Protection: IP 67; Probe length (L): 12; ATEX marking: II 2G Ex ia IIC T4 Gb. See the Specifications tab on this page for the full technical table.
Specifications
| Ambient temperature | -20...70 |
|---|---|
| Approval | DMT 03 ATEX E091; IECEx BVS 06.0007 |
| ATEX marking | II 2G Ex ia IIC T4 Gb |
| Cable | 6 m, TPE-S; Maximum cable length: 100 m; 5 x 0.34 mm² |
| Connection to control monitor | VS2000 Exi (PTB 01 ATEX 2075) |
| Greatest sensitivity | 3...40 |
| Housing | tubular |
| Installation length EL | 27 |
| Key Features | For applications in hazardous areas; Reliable monitoring of aggressive liquids in pipes; For connection to an evaluation unit; Ceramic materials for contact with the medium; Robust design for use in harsh industrial environments |
| Material | ceramics (99.7 % Al2O3) |
| Materials (wetted parts) | ceramics (99.7 % Al2O3) |
| Max. temperature gradient of medium | 7 |
| Media | Liquids; aggressive media |
| Medium temperature | 5...70 |
| MTTF | 8648 |
| Pack quantity | 1 pcs. |
| Probe diameter | 8.6 |
| Probe length (L) | 12 |
| Process Connection | threaded connection G 1/4 external thread |
| Product type | Flow sensor for connection to an evaluation unit |
| Protection | IP 67 |
| Response time | 2...20 |
| Setting range | 3...60 |
| Specification Summary | Flow sensor for connection to evaluation units; Setting range 3...60 cm/s; Medium temperature 5...70 °C; Pressure rating 30 bar; G 1/4 external thread; cable |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | SF223A |
| Product category | Flow Sensors & Meters |
| Published specifications | 24 attributes listed |
| Related part numbers | 2 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for SF223A?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the SF223A?
SF223A is made by IFM and is listed in our Flow Sensors & Meters category. KKM Solutions is an independent distributor, not an authorized IFM dealer: we source the exact IFM part number SF223A, and the quote confirms condition and lead time before you order.
Is the SF223A new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the SF223A, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of SF223A?
No published lifecycle status is on file for SF223A. IFM lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of SF223A?
Key specifications include Ambient temperature: -20...70; Approval: DMT 03 ATEX E091; IECEx BVS 06.0007; ATEX marking: II 2G Ex ia IIC T4 Gb; Cable: 6 m, TPE-S; Maximum cable length: 100 m; 5 x 0.34 mm². The full specification table on this page lists every published attribute for this part.
What material is SF223A made of?
Per the published specification for SF223A: Material: ceramics (99.7 % Al2O3). Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can SF223A ship?
Lead time for SF223A is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
