OA0108 IFM Diffuse reflection sensor
KKM Solutions is an independent parts distributor, not an authorized IFM dealer — how we source.
IFM OA0108 - Diffuse reflection sensor - Material: housing: PPO modified; Ambient temperature: -25...60.
Overview
Part number OA0108 from IFM, listed in Photoelectric Sensors. Specifications on file: Ambient temperature -25...60; Application Industrial applications; Dimensions 90 x 30 x 70; Electrical design Relay. KKM Solutions quotes this part with pricing and availability confirmed per order.
This listing covers the IFM OA0108, a part number in the Diffuse reflection sensor category. The manufacturer's published data for this part number specifies Material: housing: PPO modified.
Very long range; Intuitive setting of the sensitivity; Programmable light-on/dark-on mode; With function check output to signal soiling or maladjustment; LED display to check operation, switching status and function
Key manufacturer data on file for this item includes Ambient temperature: -25...60; Terminals: ...1.5 mm²; Cable sheath: Ø 4.5...10 mm; Cable gland: M16 X 1.5; Protection class: II; Dimensions: 90 x 30 x 70; Application: Industrial applications; Contact rating: 250 V AC / 3 A / 360 VA, 125 V DC / 3 A / 30 W; Product type: Diffuse reflection sensor; Short-circuit-proof: no; Operating voltage: 20...250 AC/DC; Max. power consumption: 2; Reverse polarity protection: no; Range: 5...1500; (white paper 200 x 200 mm). See the Specifications tab on this page for the full technical table.
Specifications
| Ambient temperature | -25...60 |
|---|---|
| Application | Industrial applications |
| Contact rating | 250 V AC / 3 A / 360 VA, 125 V DC / 3 A / 30 W |
| Dimensions | 90 x 30 x 70 |
| Electrical design | Relay |
| Frequency AC | 47...63 |
| Function principle | Diffuse reflection sensor |
| Housing | rectangular |
| Key Features | Very long range; Intuitive setting of the sensitivity; Programmable light-on/dark-on mode; With function check output to signal soiling or maladjustment; LED display to check operation, switching status and function |
| Lens alignment | Side sensing |
| Light spot dimensions refer to | at maximum range |
| Material | housing: PPO modified |
| Max. light spot diameter | 370 |
| Max. power consumption | 2 |
| MTTF | 288 |
| Operating voltage | 20...250 AC/DC |
| Output function | light-on/dark-on mode; (programmable) |
| Overload protection | no |
| Pack quantity | 1 pcs. |
| Product type | Diffuse reflection sensor |
| Protection | IP 65 |
| Protection class | II |
| Range | 5...1500; (white paper 200 x 200 mm) |
| Range adjustable | yes |
| Required protection | miniature fuse to IEC60127-2 sheet 1; ≤ 5 A; fast acting |
| Reverse polarity protection | no |
| Short-circuit-proof | no |
| Specification Summary | Diffuse reflection sensor; Infrared light; light-on/dark-on mode; (programmable); Relay; 1500 mm; IP 65; terminals: ...1,5 mm²; Cable sheath: Ø 4,5...10 mm |
| Switching frequency AC | 10 |
| Switching frequency DC | 10 |
| Terminals | ...1.5 mm²; Cable sheath: Ø 4.5...10 mm; Cable gland: M16 X 1.5 |
| Type of light | Infrared light |
| Wave length | 880 |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | OA0108 |
| Product category | Photoelectric Sensors |
| Published specifications | 33 attributes listed |
| Related part numbers | 7 other part numbers in this family |
