IGC201 IFM Inductive sensor
KKM Solutions is an independent parts distributor, not an authorized IFM dealer — how we source.
IFM IGC201 - Inductive sensor - Material: housing: brass white bronze coated; sensing face: LCP; Ambient temperature: -25...70.
Overview
Part number IGC201 from IFM, listed in Inductive Proximity Sensors. Specifications on file: Ambient temperature -25...70; Dimensions M18 x 1 / L = 51; Electrical design PNP/NPN; Housing Threaded type. KKM Solutions quotes this part with pricing and availability confirmed per order.
In our catalog, the IGC201 from IFM is listed under the Inductive sensor category. The manufacturer's published data for this part number specifies Material: housing: brass white bronze coated; sensing face: LCP.
High protection rating for the requirements of harsh industrial environments; For use in machine tools and metalworking; Resistant to oils and coolants; Two-wire technology; Long sensing range minimizes physical damage
Published specifications for this part include Ambient temperature: -25...70; Connector: 1 x M12; coding: A; Contacts: 4, gold-plated; Protection class: II; Dimensions: M18 x 1 / L = 51; Application: Industrial applications; Oils and coolants; Product type: Inductive sensor; Mounting: non-flush mountable; Operating voltage: 10...30 DC; Reverse polarity protection: yes; Sensing range: 12; Overload protection: yes; Special Feature: gold-plated contacts; Increased sensing range. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Ambient temperature | -25...70 |
|---|---|
| Application | Industrial applications; Oils and coolants |
| Connector | 1 x M12; coding: A; Contacts: 4, gold-plated |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Dimensions | M18 x 1 / L = 51 |
| Electrical design | PNP/NPN |
| Housing | Threaded type |
| Hysteresis | 3...15 |
| Increased sensing range | yes |
| Key Features | High protection rating for the requirements of harsh industrial environments; For use in machine tools and metalworking; Resistant to oils and coolants; Two-wire technology; Long sensing range minimizes physical damage |
| Material | housing: brass white bronze coated; sensing face: LCP |
| Max. leakage current | 0.5 |
| Max. voltage drop switching output DC | 2.5 |
| Minimum load current | 2 |
| Mounting | non-flush mountable |
| MTTF | 2655 |
| Operating distance | 0...9.7 |
| Operating voltage | 10...30 DC |
| Output function | normally open |
| Overload protection | yes |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 100 |
| Product type | Inductive sensor |
| Protection | IP 68; ("Coolant") |
| Protection class | II |
| Real sensing range Sr | 12 ± 10 % |
| Reverse polarity protection | yes |
| Sensing range | 12 |
| Short circuit protection | yes |
| Special Feature | gold-plated contacts; Increased sensing range |
| Specification Summary | Inductive sensor; M18 x 1 / L = 51 mm; Sensing range 12 mm non-flush mountable; normally open; DC; PNP/NPN; M12 Connector; IP 68; ("Coolant"); 2-wire; Ambient temperature -25...70 °C; Switching frequency 250 Hz |
| Switch-point drift | -10...10 |
| Switching frequency DC | 250 |
| Thread designation | M18 x 1 |
| Type of short-circuit protection | yes (non-latching) |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | IGC201 |
| Product category | Inductive Proximity Sensors |
| Published specifications | 35 attributes listed |
| Related part numbers | 15 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for IGC201?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the IGC201?
IGC201 is made by IFM and is listed in our Inductive Proximity Sensors category. KKM Solutions is an independent distributor, not an authorized IFM dealer: we source the exact IFM part number IGC201, and the quote confirms condition and lead time before you order.
Is the IGC201 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the IGC201, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of IGC201?
No published lifecycle status is on file for IGC201. IFM lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of IGC201?
Key specifications include Ambient temperature: -25...70; Application: Industrial applications; Oils and coolants; Connector: 1 x M12; coding: A; Contacts: 4, gold-plated; Correction factor: steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3. The full specification table on this page lists every published attribute for this part.
What voltage does IGC201 use?
Per the published specification for IGC201: Max. voltage drop switching output DC: 2.5; Operating voltage: 10...30 DC. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What is the current rating of IGC201?
Per the published specification for IGC201: Permanent current rating of switching output DC: 100. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What thread or connection does IGC201 use?
Per the published specification for IGC201: Thread designation: M18 x 1. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can IGC201 ship?
Lead time for IGC201 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
