Inductive sensor - IG5564
IFM IG5564 - Inductive sensor - Material: housing: PBT; Weight: 295.5; Ambient temperature: -25...80.
IFM IG5564 is a Inductive sensor catalog item from IFM. The manufacturer's published data for this part number specifies Material: housing: PBT and Weight: 295.5.
Output function normally open / normally closed programmable; Two-wire technology; Large operating voltage range; High protection rating for the requirements of harsh industrial environments; Wide operating temperature range
The specification set recorded for this part number covers Ambient temperature: -25...80; Protection class: II; Dimensions: M18 x 1 / L = 80; Product type: Inductive sensor; Mounting: non-flush mountable; Cable: 6 m, PUR / PVC; 2 x 0.5 mm²; Operating voltage: 10...55 DC; Reverse polarity protection: yes; Sensing range: 8; Overload protection: yes; Output function: normally open / closed; (selectable); Hysteresis: 1...15. The complete technical table is shown in the Specifications tab on this page.
| Ambient temperature | -25...80 |
|---|---|
| Cable | 6 m, PUR / PVC; 2 x 0.5 mm² |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Dimensions | M18 x 1 / L = 80 |
| Electrical design | PNP/NPN |
| Housing | Threaded type |
| Hysteresis | 1...15 |
| Key Features | Output function normally open / normally closed programmable; Two-wire technology; Large operating voltage range; High protection rating for the requirements of harsh industrial environments; Wide operating temperature range |
| Material | housing: PBT |
| Max. leakage current | 0.8 |
| Max. voltage drop switching output DC | 4.6 |
| Minimum load current | 4 |
| Mounting | non-flush mountable |
| MTTF | 1806 |
| Operating distance | 0...6.5 |
| Operating voltage | 10...55 DC |
| Output function | normally open / closed; (selectable) |
| Overload protection | yes |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 400 |
| Product type | Inductive sensor |
| Protection | IP 67 |
| Protection class | II |
| Real sensing range Sr | 8 ± 10 % |
| Reverse polarity protection | yes |
| Sensing range | 8 |
| Short circuit protection | yes |
| Specification Summary | Inductive sensor; M18 x 1 / L = 80 mm; Sensing range 8 mm non-flush mountable; normally open / closed; (selectable); DC; PNP/NPN; 6 m PUR / PVC-Cable; IP 67; 2-wire; Ambient temperature -25...80 °C; Switching frequency 300 Hz |
| Switch-point drift | -10...10 |
| Switching frequency DC | 300 |
| Thread designation | M18 x 1 |
| Type of short-circuit protection | yes (non-latching) |
| Weight | 295.5 |
