Inductive sensor - IG5404
IFM IG5404 - Inductive sensor - Weight: 361; Ambient temperature: -25...80; Protection class: II.
IFM IG5404 is a Inductive sensor catalog item from IFM. The manufacturer's published data for this part number specifies Weight: 361 and Ambient temperature: -25...80.
housing: brass white bronze coated; sensing face: PBT orange; end cap: PC; lock nuts: brass white bronze coated
The specification set recorded for this part number covers Protection class: II; Dimensions: M18 x 1 / L = 80; Product type: Inductive sensor; Mounting: non-flush mountable; Cable: 6 m, PVC; 3 x 0.5 mm²; Operating voltage: 10...36 DC; Current consumption: 15; Reverse polarity protection: yes; Sensing range: 8; Overload protection: yes; Output function: normally open; Hysteresis: 1...15. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -25...80 |
|---|---|
| Cable | 6 m, PVC; 3 x 0.5 mm² |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Current consumption | 15 |
| Dimensions | M18 x 1 / L = 80 |
| Electrical design | PNP |
| Housing | Threaded type |
| Hysteresis | 1...15 |
| Key Features | Robust metal housing for use in harsh industrial environments; Wide operating temperature range; High protection rating for the requirements of harsh industrial environments |
| Material | housing: brass white bronze coated; sensing face: PBT orange; end cap: PC; lock nuts: brass white bronze coated |
| Max. voltage drop switching output DC | 2.5 |
| Mounting | non-flush mountable |
| MTTF | 1853 |
| Operating distance | 0...6.5 |
| Operating voltage | 10...36 DC |
| Output function | normally open |
| Overload protection | yes |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 250 |
| Product type | Inductive sensor |
| Protection | IP 67 |
| Protection class | II |
| Real sensing range Sr | 8 ± 10 % |
| Reverse polarity protection | yes |
| Sensing range | 8 |
| Short circuit protection | yes |
| Specification Summary | Inductive sensor; M18 x 1 / L = 80 mm; Sensing range 8 mm non-flush mountable; normally open; DC; PNP; 6 m PVC-Cable; IP 67; 3-wire; Ambient temperature -25...80 °C; Switching frequency 300 Hz |
| Switch-point drift | -10...10 |
| Switching frequency DC | 300 |
| Thread designation | M18 x 1 |
| Type of short-circuit protection | yes (non-latching) |
| Weight | 361 |
