Y connection cable - EVT332
IFM EVT332 - Y connection cable - Weight: 121.8; Storage Temperature: -25...55; Ambient temperature: -25...100.
Overview
In our catalog, the EVT332 from IFM is listed under the Y connection cable category. The manufacturer's published data for this part number specifies Weight: 121.8 and Storage Temperature: -25...55.
1 x M12, straight; coding: A; Contacts: 5, gold-plated; Moulded body: PVC, orange; Locking: stainless steel (1.4404 / 316L); Tightening torque: 0.6...1.5 Nm
Key manufacturer data on file for this item includes Ambient temperature: -25...100; Protection class: II; Application: sanitary and wet areas in the food industry; Product type: Y connection cable; Cable: 1 m, PVC, orange, Ø 4.9 mm; 4 x 0.34 mm² (42 x Ø 0.1 mm ); Operating voltage: < 60 AC/DC; Special Feature: Free from silicone; gold-plated contacts; Drag chain suitability; Protection: IP 65; IP 67; IP 68; IP 69K; Sealing material: EPDM; Ambient temperature (moving): 5...100; Drag chain suitability: yes; Free from silicone: yes. See the Specifications tab on this page for the full technical table.
Specifications
| Ambient temperature | -25...100 |
|---|---|
| Ambient temperature (moving) | 5...100 |
| Application | sanitary and wet areas in the food industry |
| Cable | 1 m, PVC, orange, Ø 4.9 mm; 4 x 0.34 mm² (42 x Ø 0.1 mm ) |
| Connector | 1 x M12, straight; coding: A; Contacts: 5, gold-plated; Moulded body: PVC, orange; Locking: stainless steel (1.4404 / 316L); Tightening torque: 0.6...1.5 Nm |
| Drag chain suitability | yes |
| Free from silicone | yes |
| Key Features | For use in sanitary and wet areas in the food industry; Permanent, reliable sealing even when mounted without tools; Wide operating temperature range and high protection rating; Vibration and shock resistant thanks to coupling ring with locking mechanism; Mechanical end stop to protect the O-ring from destruction |
| Material nut | stainless steel (1.4404 / 316L) |
| Max. current load total | 4 |
| Molded-body material | PVC |
| Number of ports splitter box | 2 |
| Operating voltage | < 60 AC/DC |
| Overall current rating (UL) | 3 |
| Pack quantity | 1 pcs. |
| Product type | Y connection cable |
| Protection | IP 65; IP 67; IP 68; IP 69K |
| Protection class | II |
| Sealing material | EPDM |
| Special Feature | Free from silicone; gold-plated contacts; Drag chain suitability |
| Specification Summary | Y connection cable; Operating voltage < 60 V AC; 2; 1 m; PVC; IP 65; IP 67; IP 68; IP 69K; Free from silicone yes; gold-plated contacts yes |
| Storage humidity | 10...100 |
| Storage Temperature | -25...55 |
| Weight | 121.8 |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | EVT332 |
| KKM catalog reference | IFM-EVT332 |
| Product category | Sensor & Actuator Cordsets |
| Published specifications | 24 attributes listed |
| Related part numbers | 17 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for EVT332?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EVT332?
EVT332 is a IFM part. KKM Solutions sources IFM components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is EVT332 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for EVT332 — check IFM's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of EVT332?
Key specifications include Ambient temperature: -25...100; Ambient temperature (moving): 5...100; Application: sanitary and wet areas in the food industry; Cable: 1 m, PVC, orange, Ø 4.9 mm; 4 x 0.34 mm² (42 x Ø 0.1 mm ). The full specification table on this page lists every published attribute for this part.
How quickly can EVT332 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
