AL1030 IFM IO-Link master with EtherCAT interface
KKM Solutions is an independent parts distributor, not an authorized IFM dealer — how we source.
IFM AL1030 - IO-Link master with EtherCAT interface - Material: housing: PA; Socket: brass nickel-plated; Storage Temperature: -25...85.
Overview
Part number AL1030 from IFM, listed in I/O Modules & Remote I/O. Specifications on file: Additional voltage supply 19...31.2 DC; (UA); Ambient temperature -25...60; Application I/O modules for field applications; Communication interface Ethernet; IO-Link. KKM Solutions quotes this part with pricing and availability confirmed per order.
This listing covers the IFM AL1030, a part number in the IO-Link master with EtherCAT interface category. The manufacturer's published data for this part number specifies Material: housing: PA; Socket: brass nickel-plated.
Reliable transmission of machine data, process parameters and diagnostic data to the controller; With integrated fieldbus interface; Wide operating temperature range and high protection rating; Robust housing for use in harsh industrial environments
The specification set recorded for this part number covers Storage Temperature: -25...85; Type of mounting: Backplane mounting; Ambient temperature: -25...60; Protocol: EtherCAT; Connector: 2 x M12; coding: D; Contacts: 4; sealing: FKM; Protection class: III; Dimensions: 212 x 60 x 30.5; Number of digital inputs: 12; (IO-Link Port Class A: 4 x 2; IO-Link Port Class B: 4 x 1); Number of digital outputs: 8; (IO-Link Port Class A: 4 x 1; IO-Link Port Class B: 4 x 1); Application: I/O modules for field applications; Product type: IO-Link master with EtherCAT interface; Short-circuit-proof: yes. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Additional voltage supply | 19...31.2 DC; (UA) |
|---|---|
| Ambient temperature | -25...60 |
| Application | I/O modules for field applications |
| Communication interface | Ethernet; IO-Link |
| Connector | 2 x M12; coding: D; Contacts: 4; sealing: FKM |
| Current rating per port | 1.6 |
| Daisy-chain function | voltage supply; fieldbus interface |
| Digital inputs protected against short circuits | yes |
| Dimensions | 212 x 60 x 30.5 |
| Housing | rectangular |
| IO-Link revision | 1.1 |
| Key Features | Reliable transmission of machine data, process parameters and diagnostic data to the controller; With integrated fieldbus interface; Wide operating temperature range and high protection rating; Robust housing for use in harsh industrial environments |
| Material | housing: PA; Socket: brass nickel-plated |
| Max. current load per output | 200 |
| Max. relative air humidity | 95 |
| Number of digital inputs | 12; (IO-Link Port Class A: 4 x 2; IO-Link Port Class B: 4 x 1) |
| Number of digital outputs | 8; (IO-Link Port Class A: 4 x 1; IO-Link Port Class B: 4 x 1) |
| Number of inputs and outputs | Number of digital inputs: 12; Number of digital outputs: 8 |
| Number of ports class A | 4 |
| Number of ports class B | 4 |
| Operating voltage | 19...31.2 DC; (US) |
| Pack quantity | 1 pcs. |
| Product type | IO-Link master with EtherCAT interface |
| Protection | IP 65; IP 67 |
| Protection class | III |
| Protocol | EtherCAT |
| Sealing material | FKM |
| Short-circuit-proof | yes |
| Specification Summary | IO-Link master PowerLine; 212 x 60 x 30.5 mm; Number of digital inputs 12; Number of digital outputs 8; IP 65; IP 67 |
| Storage Temperature | -25...85 |
| Switching level high | 15...30 |
| Switching level low | -3...5 |
| Total number of inputs and outputs | 12; (configurable) |
| Transmission type | COM1 (4,8 kBaud); COM2 (38,4 kBaud); COM3 (230,4 kBaud) |
| Type of mounting | Backplane mounting |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | AL1030 |
| Product category | I/O Modules & Remote I/O |
| Published specifications | 35 attributes listed |
| Related part numbers | 4 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for AL1030?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the AL1030?
AL1030 is made by IFM and is listed in our I/O Modules & Remote I/O category. KKM Solutions is an independent distributor, not an authorized IFM dealer: we source the exact IFM part number AL1030, and the quote confirms condition and lead time before you order.
Is the AL1030 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the AL1030, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of AL1030?
No published lifecycle status is on file for AL1030. IFM lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of AL1030?
Key specifications include Additional voltage supply: 19...31.2 DC; (UA); Ambient temperature: -25...60; Application: I/O modules for field applications; Communication interface: Ethernet; IO-Link. The full specification table on this page lists every published attribute for this part.
What voltage does AL1030 use?
Per the published specification for AL1030: Operating voltage: 19...31.2 DC; (US). Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What is the current rating of AL1030?
Per the published specification for AL1030: Current rating per port: 1.6. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What material is AL1030 made of?
Per the published specification for AL1030: Material: housing: PA; Socket: brass nickel-plated. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can AL1030 ship?
Lead time for AL1030 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
