Hager VU24NC FW Distribution Box Module IP30 surface-mounted
Hager VU24NC — distribution board: glow wire test 650°C, IP30 (with door), rated 63 A.
The Hager VU24NC is a distribution board. It is supplied as a small distribution board (kleinverteiler), volta range. Published specifications for this part number include rated 63 A, rated voltage 400 V, IP30 (with door), Flush mount (Unterputz) mounting, glow wire test 650°C. Further catalogue data covers cable entry, door type, earthing terminal block, half modules per rail at 17.5 mm pitch, housing material, impact resistance, installation height x width x depth, maximum power dissipation. KKM Solutions sources Hager components to order. Request a quote from KKM Solutions for current pricing, lead time and availability.
| Cable entry | Yes |
|---|---|
| Door type | Single door, snap-latch closure, no lock |
| Earthing terminal block | Yes |
| Glow wire test | 650°C |
| Half modules per rail at 17.5 mm pitch | 48 |
| Housing material | Plastic, RAL 9010 pure white |
| Impact resistance | IK07 |
| Installation height x width x depth | 490 x 314 x 89 mm |
| IP Rating | IP30 (with door) |
| Maximum power dissipation | 17.50 W (at T=20K) |
| Mounting plate | No |
| Mounting Type | Flush mount (Unterputz) |
| Neutral terminal block | Yes |
| Number of DIN rails | 2 |
| Number of modules | 24 |
| Number of Rows | 2 |
| Overall dimensions (H x W x D) | 505.50 x 348 x 505.50 mm |
| Product type | Small distribution board (Kleinverteiler), Volta range |
| Protection class | Class II |
| Rated current | 63 A |
| Rated voltage | 400 V |
| REACh SVHC free | Yes |
| RoHS Compliant | Yes |
| Source stock status | In stock at source |
| UV resistant | Yes |
Frequently Asked Questions
How much does VU24NC cost?
VU24NC is listed at CA$81.44 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the VU24NC?
VU24NC is a Hager part. KKM Solutions sources Hager components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is VU24NC discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for VU24NC — check Hager's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of VU24NC?
Key specifications include Cable entry: Yes; Door type: Single door, snap-latch closure, no lock; Earthing terminal block: Yes; Glow wire test: 650°C. The full specification table on this page lists every published attribute for this part.
How quickly can VU24NC ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
