Formsprag Clutch FS-100 / .625 LH (CL4008-1LH)
Formsprag Clutch CL4008-1LH - Overrunning Clutches - Bore: 15.88 mm; Product Series: FS-100, 200, 300; Product category: Overrunning, Indexing, Backstopping Clutches.
CL4008-1LH/Overrunning, Indexing, Backstopping External Bearing Support Required, Sprag Clutches
| Bore | 15.88 mm |
|---|---|
| Bore Range Max | 15.88 |
| Bore Range Min | 12.7 |
| Description | CL4008-1LH/Overrunning, Indexing, Backstopping External Bearing Support Required, Sprag Clutches |
| Direction of rotation | LH |
| Family ID | 20013 |
| Family Name | Ball Bearing Supported Designs |
| Indexing Application Caution | Formsprag Clutch recommends the use of our HPI series for indexing rates in excess of 150 strokes per minute or indexing angles in excess of 90 degrees. |
| Keyway In Bore | 4.75 X 2.38 |
| Lubrication Type | Oil Lip Seal |
| Max. Inner Race RPM | 1,800 |
| Max. Outer Race RPM | 450 |
| Product category | Overrunning, Indexing, Backstopping Clutches |
| Product Mounting | Contact Formsprag Clutch Application Engineering for Vertical Mounting. |
| Product Mounting Addtl | See our Accessories section for convenient mounting options. |
| Product Series | FS-100, 200, 300 |
| Resistance After Run In | 3 |
| Resistance After Run Nm | 4.1 |
| Shipping Weight | 0.79 |
| Sub Level 2 | Ball Bearing Supported Designs |
| Torque Capacity | 95 |
| Unit of Measure | English |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for CL4008-1LH?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the CL4008-1LH?
CL4008-1LH is a Formsprag Clutch part. KKM Solutions sources Formsprag Clutch components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is CL4008-1LH discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for CL4008-1LH — check Formsprag Clutch's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of CL4008-1LH?
Key specifications include Bore: 15.88 mm; Bore Range Max: 15.88; Bore Range Min: 12.7; Description: CL4008-1LH/Overrunning, Indexing, Backstopping External Bearing Support Required, Sprag Clutches. The full specification table on this page lists every published attribute for this part.
How quickly can CL4008-1LH ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
