Dwyer Low pressure gage, range -60-0" w.c. (-15-0 kPa).
Dwyer Instruments LPG4-D7522N - Pressure Gauges - Weight: 7.3 oz; Accuracy: ± 1.5 %; Operating temperature - max: 140 °F.
Overview
This listing covers the Dwyer Instruments LPG4-D7522N, a part number in the Pressure Gauges category. The manufacturer's published data for this part number specifies Weight: 7.3 oz and Accuracy: ± 1.5 %.
Clean dry air / inert gas, Clean process / cooling water, Compatible Liquids, Inert / non-reactive gases, Oils / lubricants, Organic solvents, Water
The specification set recorded for this part number covers Operating temperature - max: 140 °F; Operating temperature - min: -40 °F; Country of origin: China; GrossWeightValue: 0.5; Materials, Wetted: Brass, Copper; Measurement Pressure, Max: 0 inH₂O; Measurement Pressure, Min: -60 inH₂O; Process Connection Size: 1/4 in; Process Connection Type: NPT Male; Proof Pressure: 100% Full Scale; Accuracy Detail: ± 1.5% FS; Applications: Fluid Measurement and Control, Level Monitoring and Control. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Accuracy | ± 1.5 % |
|---|---|
| Accuracy Detail | ± 1.5% FS |
| Applications | Fluid Measurement and Control, Level Monitoring and Control |
| Country of origin | China |
| Dial Dia | 2.5 in |
| Enclosure Ratings | IP54, NEMA Type 3 |
| GrossWeightValue | 0.5 |
| Materials | Steel, Polycarbonate |
| Materials, Wetted | Brass, Copper |
| Measurement Pressure, Max | 0 inH₂O |
| Measurement Pressure, Min | -60 inH₂O |
| Media Compatibility | Clean dry air / inert gas, Clean process / cooling water, Compatible Liquids, Inert / non-reactive gases, Oils / lubricants, Organic solvents, Water |
| Operating temperature - max | 140 °F |
| Operating temperature - min | -40 °F |
| Process Connection Size | 1/4 in |
| Process Connection Type | NPT Male |
| Process Temperature, Max | 160 °F |
| Process Temperature, Min | -40 °F |
| Proof Pressure | 100% Full Scale |
| Weight | 7.3 oz |
Product details
| Manufacturer | Dwyer Instruments |
|---|---|
| Manufacturer part number | LPG4-D7522N |
| KKM catalog reference | DWYER-LPG4-D7522N |
| Product category | Test & Measurement Instruments |
| Published specifications | 20 attributes listed |
| Related part numbers | 8 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for LPG4-D7522N?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the LPG4-D7522N?
LPG4-D7522N is a Dwyer Instruments part. KKM Solutions sources Dwyer Instruments components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is LPG4-D7522N discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for LPG4-D7522N — check Dwyer Instruments's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of LPG4-D7522N?
Key specifications include Accuracy: ± 1.5 %; Accuracy Detail: ± 1.5% FS; Applications: Fluid Measurement and Control, Level Monitoring and Control; Country of origin: China. The full specification table on this page lists every published attribute for this part.
How quickly can LPG4-D7522N ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
Variants & Related Part Numbers
Other Dwyer Instruments part numbers in this family:
- LPG4-D7122N — Dwyer Low pressure gage, range -10-0" w.c. (-2.5-0 kPa).
- LPG4-D7222N — Dwyer Low pressure gage, range -15-0" w.c. (-3.75-0 kPa).
- LPG4-D7322N — Dwyer Low pressure gage, range -25-0" w.c. (-6-0 kPa).
- LPG4-D7422N — Dwyer Low pressure gage, range -40-0" w.c. (-10-0 kPa).
- LPG4-D7622N — Dwyer Low pressure gage, range -80-0" w.c. (-20-0 kPa).
- LPG4-D7722N — Dwyer Low pressure gage, range -100-0" w.c. (-25-0 kPa).
- LPG4-D7822N — Dwyer Low pressure gage, range -160-0" w.c. (-40-0 kPa).
- LPG4-D7922N — Dwyer Low pressure gage, range -235-0" w.c. (-60-0 kPa).
