DODGE - 137937 - F4B-DLAH-103-HT-DRY

137937 Dodge F4B-DLAH-103-HT-DRY

Brand: Dodge SKU: 137937 Mfr Part #: 137937

KKM Solutions is an independent parts distributor, not an authorized Dodge dealer — how we source.

Ships worldwide — lead time quoted per part

F4B-DLAH-103-HT-DRY Ball Bearing Series: 206 Series Bearing Type: Ball Bolt Diameter: 0.4375 Bolt Diameter (Unit): INCH Bolt to Bolt (Max): 3.25 Bolt to Bolt (Max) (Unit): INCH Bolt to Bolt (Min): 3.25 Bolt to Bolt (Min) (Unit): INCH Bore Length: 1.56 Bore Length (Unit): INCH Dynamic Load Capacity:

Sourced to exact specCross-checked against manufacturer part data
Fast quote turnaroundOur order desk replies within 1 business day
Worldwide shippingWe ship to your site, warehouse, or freight forwarder

Overview

Part number 137937 from Dodge, listed in Power Transmission. KKM Solutions quotes this part with pricing and availability confirmed per order.

F4B-DLAH-103-HT-DRY Ball Bearing Series: 206 Series Bearing Type: Ball Bolt Diameter: 0.4375 Bolt Diameter (Unit): INCH Bolt to Bolt (Max): 3.25 Bolt to Bolt (Max) (Unit): INCH Bolt to Bolt (Min): 3.25 Bolt to Bolt (Min) (Unit): INCH Bore Length: 1.56 Bore Length (Unit): INCH Dynamic Load Capacity: 4368.0 Dynamic Load Capacity (Unit): POUND_FORCE Expansion Capability: Non-Expansion (Fixed) Greasable: Yes Grease Name: None Housing Construction: Solid Housing Material: Cast Iron Housing Type: Four-Bolt Flange (Square) Insert Material: Steel Lubrication: None Maximum Speed: 5500.0 Maximum Speed (Unit): RPM PT Place Flag: Yes Seal Type: Labyrinth Sensor Ready: Adapter Required Shaft Attachment: Clamp Collar Shaft Diameter: 1.1875 Shaft Diameter (Unit): INCH Standoff Housing: No Static Load Capacity: 2538.0 Static Load Capacity (Unit): POUND_FORCE Suitable for High Temperature: Yes Suitable For Washdown: No

Product details

Manufacturer Dodge
Manufacturer part number 137937
Product category Power Transmission
Related part numbers 15 other part numbers in this family

Request a quote for this part

Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.

Quotes back within 1 business day — usually the same day. Need it faster? Call (825) 454-5367, answered 24/7.

Frequently Asked Questions

How much does 137937 cost?

137937 is listed at CA$849.86 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email orderdesk@kkmsolutions.com for a volume quote.

Who manufactures the 137937?

137937 is made by Dodge and is listed in our Power Transmission category. KKM Solutions is an independent distributor, not an authorized Dodge dealer: we source the exact Dodge part number 137937, and the quote confirms condition and lead time before you order.

Is the 137937 new and genuine?

Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.

What warranty comes with the 137937, and can I return it?

Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.

What is the lifecycle status of 137937?

No published lifecycle status is on file for 137937. Dodge lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.

How quickly can 137937 ship?

Lead time for 137937 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
