Ecomatic 110 DAB Leader 1/2 HP Self Priming Water Pressure Booster Pump with 4 Gal pressure tank , 960GPH

Part number Ecomatic 110 from DAB, listed in Pumps. Specifications on file: Brands DAB; category ac pumps Booster Pumps; Horsepower 0.5 HP; Material Tanks Iron. KKM Solutions quotes this part with pricing and availability confirmed per order.

Pump with Pressure Tank TECHNICAL DATA Operating Range: ECOMATIC 110 to 130 From 1 to 21gpm with a head up to 164ft (71 psi ) Liquid quality requirements: clean, free from solids or abrasive substances, non viscous, non aggressive, non crystallized, chemically neutral, close to the characteristics of water Liquid temperature Range: From 32°F to 104°F Maximum suction depth: 26 ft Maximum ambient temp.: 104°F Maximum operating pressure: 116 psi Installation: fixed or portable in a horizontal position Special version on request other voltages and/or frequencies Features Tank membrane made in butile. Constructional features of the pump. Technopolymer pump body and motor support. Carbon/ceramic mechanical seal. Technopolymer impeller, diffuser, venturi and nozzle in ECOJET Construction of the motor Induction motor, closed and cooled with external ventilation. Rotor mounted on oversized greased sealed-for-life ball bearings to ensure silent running and a long life. Built-in thermal and current overload protection on ECOMATIC 110 Bult-in thermal and resetable overload protection on ECOMATIC 120F & 130 Motor protection: NEMA 3 Insulation class: F Advantages Designed to automatically start and stop the pump when taps are opened or closed. Compact design with pressure switch, pressure gauge, and drainage tap positioned on tank flange. fully adjustable pressure settings. More Details: Model ECOMATIC 110 Brand LEADER Manufacturer’s Warranty 1 year Limited Warranty Impeller Material Noryl Port Size (in.) 1 Flow (GPH) 960 HP 0.5 Volts AMP 110V – 1 Phase 8.0 Max. Total Head (ft.) 138 Tank Capacity (gal.) 16 Max. Suction Lift (ft.) 17 Max. PSI 60 Suction Port (in.) 1 Discharge Port (in.) 1 Self-Priming Yes Dimensions L x W x H (in.) 18 x 11 x 21 Product Weight (lbs.) 27.8 PERFORMANCE
