Carlo Gavazzi UWP30RSEXXX

UWP (Universal Web Platform) 3.0 is a monitoring gateway and controller that allows the monitoring and controlling of installations where Energy Efficiency Management, Building Automation and Car Park Guidance functions are needed. The system monitors and controls connected devices via its local bus management functions; it includes a web server with a powerful and intuitive user interface to display customised dashboards and interact with local devices and remote systems; the UWP 3.0 embedded automation server allows data to be exchanged locally or remotely via standard Internet protocols. UWP 3.0 can manage the complete lighting control system based on DALI actuators and it can operate as a BACnet/IP gateway. Features Include: WEB based universal controller with BACnet TCP / IP and Modbus TCP / IP. 15-30VDC. Up to 5000 managed signals (including variables, I/Os) shared among Energy Management, Building Automation and Car Park applications. Up to 128 Modbus devices connected to RS485 ports (64 devices each port). Up to 5 users concurrently connected to the Web-App. Up to 5 concurrent M2M connections (API connections, BACnet clients, Modbus masters). Up to 150 different products from the CG range can be connected to UWP 3.0 Internal storage capacity of 3 Gb for storing energy data and analog data. Function type: Controller House type: 2 modules Power Supply: 15-28VDC Consumption: ≤ 5 W Assembly: YOUR rail Module: System components Housing Material: Noryl, self-extinguishing V-0 (UL94) Dimensions 2-DIN module Protection degree Front: IP40; Screw terminals: IP20 Dielectric strength 4000 VAC RMS for 1 minute Rejection (CMRR) >65 dB, from 45 to 65 Hz Terminals 8 terminals, screw-type; Section: 1.5 mm2 maximum; Torque: from 0.4 to 0.8 Nm Supplied by KKM Solutions as part of our power supply range. Contact orderdesk@kkmsolutions.com for pricing and availability.
