BTS30-LDTL Autonics photoelectric sensor
KKM Solutions is an independent parts distributor, not an authorized Autonics dealer — how we source.
Autonics photoelectric sensor, rectangular, diffuse, visible red, 5-30mm sensing distance, light-on, NPN, 1 kHz switching frequency, 10.8 x 7.2 x 24.6mm body, polybutylene terephthalate, pigtail.
Overview
Part number BTS30-LDTL from Autonics, listed in Photoelectric Sensors. Specifications on file: Dimensions 10.8 x 7.2 x 24.6mm; Size 30mm. KKM Solutions quotes this part with pricing and availability confirmed per order.
Autonics photoelectric sensor, rectangular, diffuse, visible red, 5-30mm sensing distance, light-on, NPN, 1 kHz switching frequency, 10.8 x 7.2 x 24.6mm body, polybutylene terephthalate, pigtail. Specifications: Shape: Rectangular; IP Rating: IP67; Application: Small space and standard duty; Housing Size: 10.8 x 7.2 x 24.6mm body; Housing Material: Polybutylene terephthalate; Sensing Method: Diffuse; Operating Voltage: 10.8-26.4 VDC; Switching Output: NPN; Sensing Distance: 5-30mm; Operation Mode: Light-on; Switching Frequency: 1 kHz; Light Emission: Visible red; IO-Link Compatible: No; Cable Length: 6.5ft/2m; Jacket Material: PVC; Connection: Pigtail; Number of Wires: 3; Conductor Size: 28 AWG; Includes: Mounting hardware.
Specifications
| Dimensions | 10.8 x 7.2 x 24.6mm |
|---|---|
| Size | 30mm |
Product details
| Manufacturer | Autonics |
|---|---|
| Manufacturer part number | BTS30-LDTL |
| Product category | Photoelectric Sensors |
| Published specifications | 2 attributes listed |
| Related part numbers | 3 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does BTS30-LDTL cost?
BTS30-LDTL is listed at CA$168.25 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email orderdesk@kkmsolutions.com for a volume quote.
Who manufactures the BTS30-LDTL?
BTS30-LDTL is an Autonics part, sourced to the exact manufacturer specification.
What is the lifecycle status of BTS30-LDTL?
No published lifecycle status is on file for BTS30-LDTL. Autonics lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of BTS30-LDTL?
Key specifications include Dimensions: 10.8 x 7.2 x 24.6mm; Size: 30mm. The full specification table on this page lists every published attribute for this part.
How quickly can BTS30-LDTL ship?
Lead time is quoted per part and confirmed on your quote.
