Beckhoff EL7411 — EtherCAT Terminals
The EL7411 BLDC motor terminal provides high control performance in a very compact design for the medium output range of BLDC motors. Due to the fast control technology and the connection of an incremental encoder, both very high speed profiles and
| Approvals/markings | CE, UL |
|---|---|
| Connection technology | direct motor connection + feedback |
| Current consumption E-bus | typ. 190 mA |
| Current consumption power contacts | typ. 50 mA + holding current motor brake |
| Current controller frequency | 32 kHz |
| Distributed clocks | yes |
| Electrical isolation | 500 V (E-bus/field potential) |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Load type | BLDC |
| Min. motor inductance | 200 µH |
| Number Of Channels | 1 |
| Number of inputs | 2 x end position, 1 x encoder, 1 x fan diag, 3 x Hall effect sensor |
| Number of outputs | 1 x BLDC motor, 1 x motor brake, 1 x fan supply, 1 x fan mode, 1 x sensor supply, 1 x encoder supply |
| Operating Temperature | 0…55°C |
| Output current (rms) | 4.5 A |
| Output current motor brake | max. 0.5 A |
| Output current with ZB8610 (rms) | 7.0 A up to 55°C, 8.0 A up to 45°C operating temperature |
| Output voltage motor brake | 24 V DC |
| Peak current (rms) | max. 9.0 A for 1 s |
| Peak current with ZB8610 (rms) | max. 16.0 A for 1 s up to 55°C operating temperature |
| Performance increase | yes, through ZB8610 fan cartridge |
| Protect. rating/installation pos. | IP20/see documentation |
| PWM clock frequency | 16 kHz |
| Relative Humidity | 95%, no condensation |
| Rotating field frequency | 0…599 Hz |
| Special Features | compact and system-integrated |
| Storage Temperature | -25…+85°C |
| Supply voltage electronics | 24 V DC (via power contacts) |
| Supply voltage power | 8…48 V DC (external) |
| Technology | compact drive technology |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Weight | approx. 95 g |
Frequently Asked Questions
How do I get pricing for EL7411?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EL7411?
EL7411 is a Beckhoff part. KKM Solutions sources Beckhoff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of EL7411?
Key specifications include Approvals/markings: CE, UL; Connection technology: direct motor connection + feedback; Current consumption E-bus: typ. 190 mA; Current consumption power contacts: typ. 50 mA + holding current motor brake. The full specification table on this page lists every published attribute for this part.
How quickly can EL7411 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
