Beckhoff 2-port EtherCAT junction EK1122
The EK1122 2-port EtherCAT junction can be used in an EtherCAT Terminal segment at any desired position between the EtherCAT Terminals and enables configuration of EtherCAT star topologies. A modular EtherCAT star hub can be realized by using several
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, cFMus |
|---|---|
| Bus interface | 2 x RJ45 |
| Configuration | not required |
| Current consumption | typ. 220 mA |
| Data transfer medium | Ethernet/EtherCAT cable (min. Cat.5), shielded |
| Data transfer rates | 100 Mbit/s |
| Distance between stations | 100 m (100BASE-TX) |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Ex marking | ATEX: II 3 G Ex ec IIC T4 Gc IECEx: Ex ec IIC T4 Gc cFMus: Class I, Division 2, Groups A, B, C, D Class I, Zone 2, AEx ec IIC T4 Gc |
| Operating Temperature | -25…+60°C |
| Power contacts | no |
| Power Supply | from E-bus |
| Propagation delay | approx. 1 µs |
| Protect. rating/installation pos. | IP20/variable |
| Protocol | EtherCAT |
| Relative Humidity | 95%, no condensation |
| Storage Temperature | -40…+85°C |
| Task within EtherCAT system | coupling of EtherCAT junctions |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Weight | approx. 75 g |
Frequently Asked Questions
How do I get pricing for EK1122?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EK1122?
EK1122 is a Beckhoff part. KKM Solutions sources Beckhoff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of EK1122?
Key specifications include Approvals/markings: CE, CCC, UL, ATEX, IECEx, cFMus; Bus interface: 2 x RJ45; Configuration: not required; Current consumption: typ. 220 mA. The full specification table on this page lists every published attribute for this part.
How quickly can EK1122 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
Related Products
Beckhoff Beckhoff EtherCAT extension EK1110
Beckhoff Beckhoff EtherCAT Coupler with ID switch, multi-mode fiber optic…
