Bearings Limited 120BTL14H — Roller Chain Sprocket
Bearings Limited 120BTL14H - Roller Chain Sprocket - Outer Diameter: 189.7888 mm mm; Series: Taper Bushed Roller Chain Sprockets; Material: Forged 1045 Alloy Steel.
The Bearings Limited 120BTL14H is part of the Roller Chain Sprocket range in our industrial catalog. The manufacturer's published data for this part number specifies Outer Diameter: 189.7888 mm mm and Series: Taper Bushed Roller Chain Sprockets.
Published specifications for this part include Material: Forged 1045 Alloy Steel; Pitch: 1.50 in in; Bushing Size: 2517; Overall Width: 1.75 in; Operating temperature - max: 500 °F; Chain Size (Number): 120; Number of Strands: 1; Roller Diameter: 22.23 mm; Bore Type: TB Bushed; Hub type: B Type (Hub); Number of Teeth: 14; Hub Diameter: 107.95 mm. The complete technical table is shown in the Specifications tab on this page.
| Bore Type | TB Bushed |
|---|---|
| Bushing Size | 2517 |
| Bushing Type | Taper Type |
| Chain Size (Number) | 120 |
| Hardened Teeth | Hardened Teeth |
| Hub Diameter | 107.95 mm |
| Hub type | B Type (Hub) |
| Length Through Bore | 1.75 in |
| Material | Forged 1045 Alloy Steel |
| Number of Strands | 1 |
| Number of Teeth | 14 |
| Operating temperature - max | 500 °F |
| Outer Diameter | 189.7888 mm mm |
| Overall Width | 1.75 in |
| Pitch | 1.50 in in |
| Pitch Diameter | 171.2214 mm |
| Roller Diameter | 22.23 mm |
| Series | Taper Bushed Roller Chain Sprockets |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for 120BTL14H?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 120BTL14H?
120BTL14H is a Bearings Limited part. KKM Solutions sources Bearings Limited components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is 120BTL14H discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for 120BTL14H — check Bearings Limited's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 120BTL14H?
Key specifications include Bore Type: TB Bushed; Bushing Size: 2517; Bushing Type: Taper Type; Chain Size (Number): 120. The full specification table on this page lists every published attribute for this part.
How quickly can 120BTL14H ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
