Balluff BTL6-A310-M0175-A1-S115
BTL0062 (BTL6-A310-M0175-A1-S115) - Magnetostrictive linear position sensors in profile design - Style: Profile series, Mounting part: Mounting clamps, Housing material: Aluminum, Anodized, Magnets, number max.: 1, Connection: Connector, M12x1, 8-pin, Analog output: Analog, voltage 0…10 V, Analog, voltage 10…0 V, Measuring range: 175 mm, Sampling frequency max.: 1000 Hz, Resolution: ≤ 20 µm, Non-linearity max.: ±200 µm, Repeat accuracy: ≤ ± 10 µm, Operating voltage Ub: 20...28 VDC, Ambient temperature: 0...70 °C, IP rating: IP67, Approval/Conformity: CE, UKCA, cULus, WEEE - BALLUFF USA
| Ambient temperature | 0...70 °C |
|---|---|
| Analog output | Analog, voltage 0…10 V, Analog, voltage 10…0 V |
| Approval/Conformity | CE, UKCA, cULus, WEEE |
| Connection | Connector, M12x1, 8-pin |
| Housing material | Aluminum, Anodized |
| IP Rating | IP67 |
| Magnets, number max. | 1 |
| Measuring range | 175 mm |
| Mounting part | Mounting clamps |
| Non-linearity max. | ±200 µm |
| Operating voltage Ub | 20...28 VDC |
| Repeat accuracy | ≤ ± 10 µm |
| Resolution | ≤ 20 µm |
| Sampling frequency max. | 1000 Hz |
| Style | Profile series |
Frequently Asked Questions
How do I get pricing for BTL0062?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BTL0062?
BTL0062 is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of BTL0062?
Key specifications include Ambient temperature: 0...70 °C; Analog output: Analog, voltage 0…10 V, Analog, voltage 10…0 V; Approval/Conformity: CE, UKCA, cULus, WEEE; Connection: Connector, M12x1, 8-pin. The full specification table on this page lists every published attribute for this part.
How quickly can BTL0062 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
