Balluff BML-S2C0-Q53N-M604-N0-KA00,3-S284
BML0719 (BML-S2C0-Q53N-M604-N0-KA00,3-S284) - Incremental linear distance measuring system and rotary angle measuring system - Dimension: 10 x 25 x 35 mm, Connection: Cable with connector, M12x1-Male, 12-pin, 0.3 m, PUR, Housing material: PBT, Interface: Digital A/B (HTL), Resolution: 500 µm, Read distance: 0.01...6.5 mm, Non-linearity max.: ±400 µm (z=1…5 mm, y=±2 mm), Reference signal: without reference signal, Operating voltage Ub: 10...30 VDC, Ambient temperature: -20...80 °C, Procedure direction: Lengthwise to tape, Approval/Conformity: cURus, CE, WEEE - BALLUFF USA
| Ambient temperature | -20...80 °C |
|---|---|
| Approval/Conformity | cURus, CE, WEEE |
| Connection | Cable with connector, M12x1-Male, 12-pin, 0.3 m, PUR |
| Dimension | 10 x 25 x 35 mm |
| Housing material | PBT |
| Interface | Digital A/B (HTL) |
| Non-linearity max. | ±400 µm (z=1…5 mm, y=±2 mm) |
| Operating voltage Ub | 10...30 VDC |
| Procedure direction | Lengthwise to tape |
| Read distance | 0.01...6.5 mm |
| Reference signal | without reference signal |
| Resolution | 500 µm |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for BML0719?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BML0719?
BML0719 is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is BML0719 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for BML0719 — check Balluff's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of BML0719?
Key specifications include Ambient temperature: -20...80 °C; Approval/Conformity: cURus, CE, WEEE; Connection: Cable with connector, M12x1-Male, 12-pin, 0.3 m, PUR; Dimension: 10 x 25 x 35 mm. The full specification table on this page lists every published attribute for this part.
How quickly can BML0719 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
