Balluff BCC S425-0000-1A-003-VS8434-100
BCC0K96 (BCC S425-0000-1A-003-VS8434-100) - Single-ended cordsets - List price USA: 67.74 USD - Special characteristics: Washdown, Connection: M12x1-Female, angled, 5-pin, A-coded, Switching output: antivalent, Cable: PVC Shielded gray, 10 m, Drag chain compatible, Number of conductors: 4, Conductor cross-section: 0.34 mm², Cable temperature, fixed routing: -40...105 °C, Cable temperature, flexible routing: -5...105 °C, Operating voltage Ub: 250 VDC / 250 VAC, Rated current (40 °C): 4.0 A, IP rating: IP67, IP68, IP69K, Cable jacket, color: gray, Approval/Conformity: CE, cULus, Ecolab, WEEE - BALLUFF USA
| Approval/Conformity | CE, cULus, Ecolab, WEEE |
|---|---|
| Cable | PVC Shielded gray, 10 m, Drag chain compatible |
| Cable jacket, color | gray |
| Cable temperature, fixed routing | -40...105 °C |
| Cable temperature, flexible routing | -5...105 °C |
| Conductor cross-section | 0.34 mm² |
| Connection | M12x1-Female, angled, 5-pin, A-coded |
| IP Rating | IP67, IP68, IP69K |
| Number of Conductors | 4 |
| Operating voltage Ub | 250 VDC / 250 VAC |
| Rated current (40 °C) | 4.0 A |
| Special characteristics | Washdown |
| Switching output | antivalent |
Frequently Asked Questions
How do I get pricing for BCC0K96?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BCC0K96?
BCC0K96 is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of BCC0K96?
Key specifications include Approval/Conformity: CE, cULus, Ecolab, WEEE; Cable: PVC Shielded gray, 10 m, Drag chain compatible; Cable jacket, color: gray; Cable temperature, fixed routing: -40...105 °C. The full specification table on this page lists every published attribute for this part.
How quickly can BCC0K96 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
