Balluff BIS M-874-1-008-X-001-3003
BAE00ZE (BIS M-874-1-008-X-001-3003) - Portable HF read/write units (13.56 MHz) - Product Group: HF (13.56 MHz), Product name: WLAN, Dimension: 100 x 51 x 265 mm, Antenna type: round, Supported data carrier types: DIN ISO 14443, DIN ISO 15693, Use: for data carriers Ø ≥ 20 mm, Display: TFT Touchscreen-Display (color) 480x640 VGA resolution, Keypad: 52 keys, alphanumeric, Operating voltage Ub: 3.7 V DC Battery pack, Storage temperature: -40...60 °C, Ambient temperature: -10...50 °C, IP rating: IP65, Approval/Conformity: CE, WEEE, EAC - BALLUFF USA
| Ambient temperature | -10...50 °C |
|---|---|
| Antenna type | round |
| Approval/Conformity | CE, WEEE, EAC |
| Dimension | 100 x 51 x 265 mm |
| Display | TFT Touchscreen-Display (color) 480x640 VGA resolution |
| IP Rating | IP65 |
| Keypad | 52 keys, alphanumeric |
| Operating voltage Ub | 3.7 V DC Battery pack |
| Product group | HF (13.56 MHz) |
| Product Name | WLAN |
| Storage Temperature | -40...60 °C |
| Supported data carrier types | DIN ISO 14443, DIN ISO 15693 |
| Use | for data carriers Ø ≥ 20 mm |
Frequently Asked Questions
How do I get pricing for BAE00ZE?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BAE00ZE?
BAE00ZE is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of BAE00ZE?
Key specifications include Ambient temperature: -10...50 °C; Antenna type: round; Approval/Conformity: CE, WEEE, EAC; Dimension: 100 x 51 x 265 mm. The full specification table on this page lists every published attribute for this part.
How quickly can BAE00ZE ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
