Allen-Bradley 889D-F4BBP3M-5 — 889 Cordsets and Patchcords
Allen-Bradley 889D-F4BBP3M-5 - 889 Cordsets and Patchcords - Cable length: 5000 mm; Number of poles: 4; Cable type: PVC cable, black, unshielded, 24 AWG.
In our catalog, the 889D-F4BBP3M-5 from Allen-Bradley is listed under the 889 Cordsets and Patchcords category. The manufacturer's published data for this part number specifies Cable length: 5000 mm and Number of poles: 4.
Standard- Epoxy coated Zinc for DC micro,AC micro, mini QD with 2-6 pin, Standard-Nickel plated Brass for pico, Standard-Aluminum with clear sealant for mini QD with 7-12 pin
Key manufacturer data on file for this item includes Cable type: PVC cable, black, unshielded, 24 AWG; Length, approx: Connector: 50.8 mm (2.0 in) @ straight male; Material housing: Plastic; Height, approx: Connector: 31.8 mm (1.25 in) @ right angle male; Wire size: 24 AWG; Mounting method: Freely positionable; Material of contact surface: Gold; Number Of Pins: 4-pin; Bend radius: 10 x diam; First end connector style: Female, straight (internal threads, except mini receptacles); Second end conductors: 3-pin; Second end termination style: Straight, male (external threads). See the Specifications tab on this page for the full technical table.
| Bend radius | 10 x diam |
|---|---|
| Cable length | 5000 mm |
| Cable type | PVC cable, black, unshielded, 24 AWG |
| Diameter, approx | Connector: 14 mm (0.56 in) @ straight male |
| Estimated Lead Time | 5 days |
| First End Connection | Female, Straight (int threads),Female, Straight (Int Threads) |
| First end connector style | Female, straight (internal threads, except mini receptacles) |
| First End Number of pins | 3-pin |
| Height, approx | Connector: 31.8 mm (1.25 in) @ right angle male |
| Jacket | PVC Cbl, Black, UnShld,PVC Cable, Black, 24 AWG |
| Length, approx | Connector: 50.8 mm (2.0 in) @ straight male |
| Material housing | Plastic |
| Material of contact surface | Gold |
| Mounting method | Freely positionable |
| Number Of Pins | 4-pin |
| Number of poles | 4 |
| Product Type Feature | Standard- Epoxy coated Zinc for DC micro,AC micro, mini QD with 2-6 pin, Standard-Nickel plated Brass for pico, Standard-Aluminum with clear sealant for mini QD with 7-12 pin |
| Screw-in thread | M8 |
| Second end conductors | 3-pin |
| Second End Connection | Male, Straight (ext. threads),Pico,Straight, Male(Ext. Threads),Pico (M8) |
| Second end termination style | Straight, male (external threads) |
| Second End Termination Type | Pico M8 |
| Standard Warranty Duration | 1 year |
| Type of plug-in contact, inner side | Female (bus) |
| UPC | 885630572505 |
| Wire size | 24 AWG |
