836T-T351JX26 Allen-Bradley Electro-Mech Pres Cntrl Sw
Allen-Bradley 836T-T351JX26 - industrial components - Width: 88.9 mm; Height: 182 mm; Operating Temperature: -22 °F.
Overview
Allen-Bradley 836T-T351JX26 is an industrial components catalog item from Allen-Bradley. The manufacturer's published data for this part number specifies Width: 88.9 mm and Height: 182 mm.
3/8 in. N.P.T.F. female pipe thread SAE 7/16-20 UNF-2B thread O-ring boss seal SAE 9/16-18 UNF-2B thread O-ring boss seal
Published specifications for this part include Operating Temperature: -22 °F; Storage Temperature: -22 °F; Electrical connection: Plug; Lifecycle Status: Active; Enclosure Type: Type 1, 4 & 13 industrial use; Degree of protection (IP): IP66; Depth: 76.7 mm; Style: Pressure control; Actuator type: Piston with seal; Utilization category: IEC: AC-15, DC-13, NEMA: A600; Operator Type: Piston with seal; Rated operational current, break: 720VA @ 72...120V AC. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Actuator type | Piston with seal |
|---|---|
| Adjustable differential | 100 psi |
| Adjustable operating range | 140 to 1000 psi |
| Contact block modification | S.P.D.T. 2-circuit contact block-standard |
| Customization | Standard trip/reset settings (the maximum operating range and minimum differential will be factory set for the pressure control switch.) |
| Degree of protection (IP) | IP66 |
| Depth | 76.7 mm |
| Electrical connection | Plug |
| Enclosure Type | Type 1, 4 & 13 industrial use |
| Explosion-proof | false |
| Height | 182 mm |
| Lifecycle Status | Active |
| Modification | Diaphragm and O-ring assembly, diaphragm is made of viton and nomex fabric, o-ring is made of Viton.Required when phosphate ester base and other adverse hydraulic fluids are present. |
| Modifications | Diaphragm and O-Ring Assembly |
| Occasional surge pressures, max | 10000 psi |
| Operating Temperature | -22 °F |
| Operator Type | Piston with seal |
| Pressure connection | 3/8 in. N.P.T.F. female pipe thread SAE 7/16-20 UNF-2B thread O-ring boss seal SAE 9/16-18 UNF-2B thread O-ring boss seal |
| Rated operational current, break | 720VA @ 72...120V AC |
| Rated operational current, make | 7200VA @ 120...600V AC |
| Storage Temperature | -22 °F |
| Style | Pressure control |
| Suitable for oil | true |
| Suitable for water | true |
| Utilization category | IEC: AC-15, DC-13, NEMA: A600 |
| Width | 88.9 mm |
Product details
| Manufacturer | Allen-Bradley |
|---|---|
| Manufacturer part number | 836T-T351JX26 |
| Product category | Contactor Parts & Accessories |
| Manufacturer lifecycle status | Active |
| Published specifications | 26 attributes listed |
| Related part numbers | 18 other part numbers in this family |
