Allen-Bradley 802M-ATJ1 — Limit Switches
Allen-Bradley 802M-ATJ1 - Limit Switches - Mode of operation: CW and CCW ops; Degree of protection (IP): IP67; Degree of protection (NEMA): 13.
This listing covers the Allen-Bradley 802M-ATJ1, a part number in the Limit Switches category. The manufacturer's published data for this part number specifies Mode of operation: CW and CCW ops and Degree of protection (IP): IP67.
0...80° (32...176°), minimum temperature based on the absence of freezing moisture or water
Published specifications for this part include Degree of protection (NEMA): 13; With status indication: False; Switching function latching: False; Suitable for safety functions: False; UPC: 662073706717; Number of circuits: 4 circuit; Special Feature: Complete switch; Actuation type: Lever type, spring return, standard trip; Construction type housing: Cuboid; List of degrees of protection (NEMA): 1, 4, 6P, 13; NEMA rating designation: 4 circuits same polarity: B300, AC; Indicating lights: Not Applicable. The complete technical table is shown in the Specifications tab on this page.
| Actuation type | Lever type, spring return, standard trip |
|---|---|
| Ambient temperature | 0...80° (32...176°), minimum temperature based on the absence of freezing moisture or water |
| Ambient temperature during operating | 0 °C |
| Connection type | 5-pin mini plug in receptacle on a 2 circuit contact block or a 9-pin plug in receptacle on a 4 circuit contact block |
| Construction type housing | Cuboid |
| Contact rating, break | 4 circuits same polarity: maximum 360VA per pole @ 240V AC @ 50/60Hz, B300 |
| Contact rating, make | 4 circuits same polarity: maximum 3600VA per pole @ 240V AC @ 50/60Hz, B300 |
| Continuous carrying current | 4 circuits same polarity: maximum 5 A per pole @ 240V AC @ 50/60Hz, B300 |
| Degree of protection (IP) | IP67 |
| Degree of protection (NEMA) | 13 |
| Estimated Lead Time | 28 days |
| Height of sensor, approx | 4 circuit: 57.9 mm |
| Indicating lights | Not Applicable |
| Length of sensor, approx | 4 circuit: 132.4 mm |
| List of degrees of protection (NEMA) | 1, 4, 6P, 13 |
| Mode of operation | CW and CCW ops |
| NEMA rating designation | 4 circuits same polarity: B300, AC |
| Number of circuits | 4 circuit |
| Output electronic | False |
| Special Feature | Complete switch |
| Standard Warranty Duration | 1 year |
| Suitable for safety functions | False |
| Switching function latching | False |
| Torque to operate contacts, max | 0.34 Nm |
| Travel to operate contacts, max | 15° |
| Travel to reset contacts, max | 6° |
| Travel, max | 86° |
| UPC | 662073706717 |
| Width of sensor, approx | 4 circuit: 44.4 mm |
| With status indication | False |
