Allen-Bradley 800T PB,30mm Momentary Push Button,Flush Head Push Button,Flush Head,Black,Standard,Standard,Black,Finger Guards on Terminals,1 NCLB 1 NO Standard Contacts,No Block In Position 2,No Block In Position 3,1 NCLB 1 NO Standard Contacts,No Block In Position 4,

Allen-Bradley 800TC-A2A1 — Pushbuttons

Brand: Allen-Bradley SKU: 800TC-A2A1 Mfr Part #: 800TC-A2A1
Ships Same Day* Worldwide Shipping

Allen-Bradley 800TC-A2A1 - Pushbuttons - Operating Temperature: -25 °C; Storage Temperature: -40 °C; Type: 30mm Momentary Push Button.

Sourced to exact specCross-checked against manufacturer part data
Fast quote turnaroundOur order desk replies within 1 business day
Worldwide shippingWe ship to your site, warehouse, or freight forwarder

In our catalog, the 800TC-A2A1 from Allen-Bradley is listed under the Pushbuttons category. The manufacturer's published data for this part number specifies Operating Temperature: -25 °C and Storage Temperature: -40 °C.

Key manufacturer data on file for this item includes Type: 30mm Momentary Push Button; Shock: 25 G (contact fragility)/100 G (no damage); Vibration: 10 G maximum; Humidity: 50 %; Type of electric connection: Screw connection; Operator Type: Push button; Contact block configuration: 1 NCLB, 1 NO, standard contact block (800T-XA1); Contact block electrical design life (cycles, at max. load): 1000000; Contact block operational voltage, max: 600V AC @ 600V DC; Contact block termination tightening torque: 6 - 8 in-lb / 0.7 - 0.9 N-m; Contact block termination wire range: 14 - 18 AWG (x2); Contact block thermal current rating: 10 A. See the Specifications tab on this page for the full technical table.

Contact block configuration 1 NCLB, 1 NO, standard contact block (800T-XA1)
Contact block electrical design life (cycles, at max. load) 1000000
Contact block operational voltage, max 600V AC @ 600V DC
Contact block termination tightening torque 6 - 8 in-lb / 0.7 - 0.9 N-m
Contact block termination wire range 14 - 18 AWG (x2)
Contact block thermal current rating 10 A
Contact block utilization category (AC) A600, AC-15
Contact block utilization category (DC) Q600, DC-13
Enclosure compatibility (NEMA type) 1, 4, 12, 13
Estimated Lead Time 21 days
Hazardous location rating False
Hole diameter 30.5 mm
Humidity 50 %
Operating Temperature -25 °C
Operator cap color Black
Operator cap type Flush head
Operator cap/button material Plastic
Operator cap/button shape Round
Operator cap/button size 30 mm
Operator construction/material Metal
Operator function Momentary contact
Operator mechanical design life (cycles, min.) 1.0E7
Operator Type Push button
Shock 25 G (contact fragility)/100 G (no damage)
Standard Warranty Duration 1 year
Storage Temperature -40 °C
Suitable for illumination False
Terminations with finger safe covers True
Type 30mm Momentary Push Button
Type of electric connection Screw connection
UPC 611320881417
Vibration 10 G maximum

Request a quote for this part

Email [email protected] or call (825) 454-5367 for pricing and availability.

Quotes back within 1 business day — usually the same day. Need it faster? Call (825) 454-5367, answered 24/7.

Frequently Asked Questions

How do I get pricing for 800TC-A2A1?

KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.

Who manufactures the 800TC-A2A1?

800TC-A2A1 is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.

Is 800TC-A2A1 discontinued, and can I still get one?

KKM Solutions does not publish a manufacturer lifecycle status for 800TC-A2A1 — check Allen-Bradley's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.

What are the key specifications of 800TC-A2A1?

Key specifications include Contact block configuration: 1 NCLB, 1 NO, standard contact block (800T-XA1); Contact block electrical design life (cycles, at max. load): 1000000; Contact block operational voltage, max: 600V AC @ 600V DC; Contact block termination tightening torque: 6 - 8 in-lb / 0.7 - 0.9 N-m. The full specification table on this page lists every published attribute for this part.

How quickly can 800TC-A2A1 ship?

In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.

Variants & Related Part Numbers

Other Allen-Bradley part numbers in this family:

  • 800TC-16HAH2KB6DX — Allen-Bradley 30mm Selector Switch 800T PB 800TC-16HAH2KB6DX
  • 800TC-2HGH2KB6AX — Allen-Bradley 30mm Selector Switch 800T PB 800TC-2HGH2KB6AX
  • 800TC-2JGH17KB7AX — Allen-Bradley 30mm Selector Switch 800T PB 800TC-2JGH17KB7AX
  • 800TC-2JGH2KB7AX — Allen-Bradley 30mm Selector Switch 800T PB 800TC-2JGH2KB7AX
  • 800TC-2JRH20KB7AX — Allen-Bradley 30mm Selector Switch 800T PB 800TC-2JRH20KB7AX
  • 800TC-2JRH5KB7CX — Allen-Bradley 30mm Selector Switch 800T PB 800TC-2JRH5KB7CX
  • 800TC-A1D1 — 800T PB,30mm Momentary Push Button,Flush Head Push Button,Flush Head,Green,Standard,Standard,Green,Finger Guards on Terminals,1…
  • 800TC-A2A4 — 800T PB,30mm Momentary Push Button,Flush Head Push Button,Flush Head,Black,Standard,Standard,Black,Finger Guards on Terminals,1…
  • 800TC-A2D1V — 800T PB,30mm Momentary Push Button,Flush Head Push Button,Flush Head,Black,Standard,Standard,Black,Finger Guards on Terminals,1…
  • 800TC-A3A2 — Allen-Bradley 800TC-A3A2 800T PB,30mm Momentary Push Button,Flush Head Push Button,Flush Head,Orange,Standard,Standard,Orange,Finger Guards…
  • 800TC-A3B — Allen-Bradley 800TC-A3B 800T PB,30mm Momentary Push Button,Flush Head Push Button,Flush Head,Orange,Standard,Standard,Orange,Finger Guards…
  • 800TC-A5AV — Allen-Bradley 30mm Momentary Push Button 800T PB 800TC-A5AV
  • 800TC-A6A — Allen-Bradley 30mm Momentary Push Button 800T PB 800TC-A6A
  • 800TC-B6A — 800T PB,30mm Momentary Push Button,Extended Head Push Button,Extended Head,Red,Standard,Standard,Red,Finger Guards on Terminals,1…
  • 800TC-FXMQH2RA7 — Allen-Bradley 30mm Push-Pull Device 800T PB 800TC-FXMQH2RA7
  • 800TC-H48BV — Allen-Bradley 30mm Selector Switch 800T PB 800TC-H48BV
  • 800TC-Q10 — Allen-Bradley 30mm Pilot Light 800T PB 800TC-Q10
  • 800TC-XD6 — Contact Block,Mini,30mm Push Button,Finger Safe Terminal,1 Normally Closed Contact

Related Products

Allen-Bradley 800T PB,30mm Momentary Push Button,Flush Head Push Button,Flush Head,Red,Standard,Standard,Red,Finger Guards on Terminals,1 NO 1 NC Standard Contacts,1 NO 1 NC Standard Contacts,No Block In Position 3,2 NO 2 NC Standard Contacts,No Block In Position 4,Dev Allen-Bradley
