Allen-Bradley 800F PB,22mm Selector Switch,Keyed Selector Switch,LEFT,3825 Standard,No Power Module (Lamp Type),Maintained, 3 Position,No Power Module,Plastic,No Power Module (Voltage)

Allen-Bradley 800FP-KM31 — 800F Key Selector Switch

Brand: Allen-Bradley SKU: 800FP-KM31 Mfr Part #: 800FP-KM31
Ships Same Day* Worldwide Shipping

Allen-Bradley 800FP-KM31 - 800F Key Selector Switch - Operating Temperature: -25 °C; Storage Temperature: -40 °C; Type: 22mm Selector Switch.

Sourced to exact specCross-checked against manufacturer part data
Fast quote turnaroundOur order desk replies within 1 business day
Worldwide shippingWe ship to your site, warehouse, or freight forwarder

The Allen-Bradley 800FP-KM31 is part of the 800F Key Selector Switch range in our industrial catalog. The manufacturer's published data for this part number specifies Operating Temperature: -25 °C and Storage Temperature: -40 °C.

The specification set recorded for this part number covers Type: 22mm Selector Switch; Type of control element: Key; Shock: 100 G; Vibration: 10 G; Humidity: ≤95% RH from 25...60 °C (77...140 °F); Operator Type: Keyed selector switch; Contact block thermal current rating: 10 A; Hole diameter: 22.5 mm; Operator cap/button material: Plastic; Operator construction/material: Plastic; Operator function: Maintained, 3 position; Operator mechanical design life (cycles, min.): 1000000. See the Specifications tab on this page for the full technical table.

Contact block thermal current rating 10 A
Enclosure compatibility IP66, Type 4/13 (round plastic operator)
Estimated Lead Time 29 days
Hole diameter 22.5 mm
Humidity ≤95% RH from 25...60 °C (77...140 °F)
Key lock, standard 3825
Key removal position Left
Latch material Plastic
Material front ring Plastic
Number of switch positions 3
Operating Temperature -25 °C
Operator cap/button material Plastic
Operator construction/material Plastic
Operator function Maintained, 3 position
Operator mechanical design life (cycles, min.) 1000000
Operator Type Keyed selector switch
Shock 100 G
Spring-return False
Standard Warranty Duration 1 year
Storage Temperature -40 °C
Suitable for illumination False
Switching function latching True
Type 22mm Selector Switch
Type of control element Key
UPC 662468100625
Vibration 10 G
With front ring True

Request a quote for this part

Email [email protected] or call (825) 454-5367 for pricing and availability.

Quotes back within 1 business day — usually the same day. Need it faster? Call (825) 454-5367, answered 24/7.

Frequently Asked Questions

How do I get pricing for 800FP-KM31?

KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.

Who manufactures the 800FP-KM31?

800FP-KM31 is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.

Is 800FP-KM31 discontinued, and can I still get one?

KKM Solutions does not publish a manufacturer lifecycle status for 800FP-KM31 — check Allen-Bradley's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.

What are the key specifications of 800FP-KM31?

Key specifications include Contact block thermal current rating: 10 A; Enclosure compatibility: IP66, Type 4/13 (round plastic operator); Estimated Lead Time: 29 days; Hole diameter: 22.5 mm. The full specification table on this page lists every published attribute for this part.

How quickly can 800FP-KM31 ship?

In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
