Allen-Bradley 22mm Selector Switch 800F PB 800FM-LSM33PN3GX20
Allen-Bradley 800FM-LSM33PN3GX20 - Selector Switches - Product Series: A; Operating Temperature: -25 °C; Storage Temperature: -40 °C.
In our catalog, the 800FM-LSM33PN3GX20 from Allen-Bradley is listed under the Selector Switches category. The manufacturer's published data for this part number specifies Product Series: A and Operating Temperature: -25 °C.
The specification set recorded for this part number covers Storage Temperature: -40 °C; Lifecycle Status: Active; Type of control element: Short thumb-grip; Shock: 100 G; Vibration: 10 G; Humidity: ≤95% RH from 25...60 °C (77...140 °F); Type of electric connection: Screw connection; Operator Type: Illuminated selector switch; Contact block configuration: 2 NO; Contact block operational voltage, max: 600V (A600, Q600) - screw termination; Contact block termination tightening torque: 6 - 8 in-lb / 0.7 - 0.9 N-m; Contact block termination wire range: #18...12 AWG (0.75...2.5 mm²). The complete technical table is shown in the Specifications tab on this page.
| Contact block configuration | 2 NO |
|---|---|
| Contact block durability | 1.0E7 |
| Contact block mounting style | Latch |
| Contact block operational voltage, max | 600V (A600, Q600) - screw termination |
| Contact block termination tightening torque | 6 - 8 in-lb / 0.7 - 0.9 N-m |
| Contact block termination wire range | #18...12 AWG (0.75...2.5 mm²) |
| Contact block thermal current rating | 10 A |
| Contact block type | Standard |
| Contact block utilization category (AC) | A600, AC 15 - screw termination |
| Contact block utilization category (DC) | Q600, DC-13 - screw termination |
| Enclosure compatibility | IP66, Type 4/13 (Round metal operator) |
| Environmental Compliance | <a href='https://www.rockwellautomation.com/en-us/company/product-environmental-compliance.html'>See Details</a> | <a href='#modal-submit-inquiry'>Submit Inquiry</a> |
| Hazardous location rating | false |
| Hole diameter | 22.5 mm |
| Humidity | ≤95% RH from 25...60 °C (77...140 °F) |
| Illumination lamp type | LED |
| Illumination module input voltage | 24V AC/DC |
| Illumination module mounting style | Latch |
| Illumination module termination tightening torque | 6 - 8 in-lb / 0.7 - 0.9 N-m |
| Illumination module termination wire range | #18...12 AWG (0.75...2.5 mm²) |
| Illumination module type | LED |
| Lamp type | Green LED |
| Latch material | Plastic |
| Lifecycle Status | Active |
| Material front ring | Metal |
| Number of contacts as normally open contact | 2 |
| Number of switch positions | 3 |
| Operating Temperature | -25 °C |
| Operator cap color | Green |
| Operator cap/button material | Metal |
| Operator construction/material | Metal |
| Operator function | Maintained, 3 position |
| Operator mechanical design life (cycles, min.) | 1000000 |
| Operator Type | Illuminated selector switch |
| Packaging | Standard pack (1 per package) |
| Power module type | Integrated LED module |
| Product Series | A |
| Shock | 100 G |
| Spring-return | false |
| Storage Temperature | -40 °C |
| Suitable for illumination | true |
| Supply voltage | 24 V |
| SVHC Information | <a href='https://literature.rockwellautomation.com/idc/groups/literature/documents/td/pec-td011_-en-e.pdf'>View Guidance</a> |
| Switch orientation | Standard |
| Switching function latching | true |
| Termination style | Screw |
| Type of control element | Short thumb-grip |
| Type of electric connection | Screw connection |
| Vibration | 10 G |
| With light source | true |
