1783-RMS10T Allen-Bradley Allen-Bradley

Allen-Bradley 1783-RMS10T Overview The Allen-Bradley 1783-RMS10T is a 10-port unmanaged Ethernet switch from the Stratix 2000 series , offering simple plug-and-play connectivity for industrial Ethernet networks. With support for 10/100 Mbps auto-negotiation , this DIN rail-mounted switch provides a reliable solution for small to mid-size network expansions in control systems that do not require managed features. Key Features Switch Type: Unmanaged industrial Ethernet switch Number of Ports: 10 copper ports Port Speed: 10/100 Mbps, auto-sensing Mounting: DIN rail Enclosure Type: Industrial plastic housing Plug-and-Play: No configuration required Status LEDs: Link and activity indicators for each port Power Supply: 12–48V DC Technical Specifications Catalog Number: 1783-RMS10T Power Input: 12–48V DC (redundant input supported) Max Power Consumption: < 5W Operating Temperature: -40°C to +60°C Relative Humidity: 5–95%, non-condensing Enclosure Rating: IP30 Certifications: UL, CE, c-UL-us, RoHS Dimensions (HxWxD): Approx. 115 x 45 x 90 mm Applications Small industrial Ethernet networks OEM equipment and machine-level networking Non-critical control system connectivity Manufacturing, packaging, and assembly lines Cost-effective network segmentation Why Choose the 1783-RMS10T Simple and fast deployment for basic Ethernet networking Reliable performance in demanding industrial environments DIN rail design for easy integration in control panels Compatible with Allen-Bradley PLCs and automation systems Proven Stratix series quality and support Order Now The Allen-Bradley 1783-RMS10T Stratix 2000 unmanaged switch is in stock and ships worldwide.
