1783-BMS12T4E2CGP Allen-Bradley Drives & Motors
Allen-Bradley 1783-BMS12T4E2CGP - Drives & Motors - Width: 12.7 cm mm; Height: 12.95 cm mm; Conformal Coating: False.
Overview
Allen-Bradley 1783-BMS12T4E2CGP — Drives & Motors. Specs: Width: 12.7 cm · Height: 12.95 cm · Conformal Coating: False · Depth: 13.58 cm · Protection type: Alarm not rated · Mounting method: DIN rail (top hat rail) · Selectable start times: T4 · Network: Ethernet. Quoted per order by KKM Solutions.
Specifications
| Alarm relay at 30V DC | 1 A |
|---|---|
| Alarm relay at 48V DC | 0.5 A |
| Approximate weight | 1.11 kg |
| CIP Sync | True |
| CIP Sync (IEEE 1588) | True |
| Conformal Coating | False |
| Depth | 13.58 cm |
| DLR | True |
| EFT/B immunity for IEC 61000-4-4 at 5 kHz on alarm ports | ±4 |
| EFT/B immunity for IEC 61000-4-4 at 5 kHz on DC power ports | ±4 |
| EFT/B immunity for IEC 61000-4-4 at 5 kHz on Ethernet ports | ±4 |
| Emissions, CISPR11 (IEC 61000-6-4) | Class A |
| ESD immunity, IEC 61000-4-2, air discharges | 8 kV |
| ESD immunity, IEC 61000-4-2, contact discharges | 6 kV |
| Ethernet | True |
| Ethernet data rate | 10/100 Mbps |
| Fiber ports | |
| Firmware type | Full |
| Height | 12.95 cm |
| Housing base material | Open-style |
| Layer 2 | False |
| Layer 3 | False |
| Manageable | True |
| Max. PoE power | 30 W |
| Maximum insulation, DC power connection | 1.2 mm |
| Mounting method | DIN rail (top hat rail) |
| NAT | False |
| Network | Ethernet |
| Nominal position | T4 |
| Number of combination ports 10/100/1000 Mbps | 2 |
| Number of combination-ports RJ45/Mini GBIC | 2 |
| Number of ports 10/100 Mbps RJ45 | 12 |
| Number of ports PoE | 4 |
| PoE ports | 4 |
| Port | 18 |
| Power consumption at 24V DC, 40 ˚C | 15 W |
| Power consumption, maximum | 30 W |
| Power dissipation | 30 W |
| Power input at 12 - 48V DC, class 2/SELV | 0.5 A |
| Power over Ethernet | 802.3 af (PoE) |
| Power over Ethernet input power, DC | 48 V |
| Protection type | Alarm not rated |
| RJ45 ports | 12 FE |
| Screw torque, ground terminal, maximum | 0.96 nm |
| Screw torque, power and alarm terminals | 0.23 nm |
| Selectable start times | T4 |
| SFP slots | |
| Shock, non-operating, IEC 60068-2-27 (test Ea, unpackaged shock) | 50 g |
| Shock, operating, IEC 60068-2-27 (test Ea, unpackaged shock) | 30 g |
| Standard Warranty Duration | 1 year |
| SW Type | Full |
| Temperature, operating, IEC 60068-2-1 (test Ad, operating, cold) | -40 °C |
| Temperature, surrounding air, maximum | 60 °C |
| Total number of ports | 18 |
| UPC | 885630556772 |
| Vibration, IEC 60068-2-6 (test Fc, operating) at 10 - 500 Hz | 2 g |
| Width | 12.7 cm |
| Wire size, ethernet connection | RJ45 connector according to IEC 60603-7, 2 or 4-pair category 5e minimum cable according to TIA 568-B.1 or category 5 cable according to ISO/IEC 24702 |
| Wire size, ground connection, stranded copper wire, minimum | 4 mm² |
| Wire strip length, alarm connection | 6.3±0.5 |
| Wire strip length, DC power connection | 6.3±0.5 |
| Wiring category on console and alarm ports | 3 |
| Wiring category on DC power ports | 2 |
| Wiring category on Ethernet ports | 2 |
Product details
| Manufacturer | Allen-Bradley |
|---|---|
| Manufacturer part number | 1783-BMS12T4E2CGP |
| KKM catalog reference | Allen Bradley-1783-BMS12T4E2CGP |
| Product category | Electric Motors |
| Published specifications | 64 attributes listed |
| Related part numbers | 2 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 1783-BMS12T4E2CGP cost?
1783-BMS12T4E2CGP is listed at CA$4,032.03 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the 1783-BMS12T4E2CGP?
1783-BMS12T4E2CGP is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What is the lifecycle status of 1783-BMS12T4E2CGP?
We do not hold a published lifecycle status for 1783-BMS12T4E2CGP. Allen-Bradley's publishes whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the current status with the manufacturer at quote time — you are told if the part is superseded or discontinued before you commit. Either way we source current-production, superseded and long-obsolete parts the same way; where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 1783-BMS12T4E2CGP?
Key specifications include Alarm relay at 30V DC: 1 A; Alarm relay at 48V DC: 0.5 A; Approximate weight: 1.11 kg; CIP Sync: True. The full specification table on this page lists every published attribute for this part.
How quickly can 1783-BMS12T4E2CGP ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
