Power Supply, 240W, 1PH, 24 28VDC, 10A, Buil in redundancy, Spring clamp terminals
| Adjustment range | Fixed |
|---|---|
| DC OK relay contact | True |
| Degree of protection (IP) | IP20 |
| Depth | 117 mm |
| Derating | 6 W/°C |
| Direct mounting possible | False |
| Efficiency | 94.7 % typical |
| Estimated Lead Time | 115 days |
| External input fuse, min | B-6 A or C-6 A |
| Height | 124 mm mm |
| Hot-swap | False |
| Input inrush current | 6 A/9 A |
| Input inrush current limiter | Active |
| Lifetime, min | 109 kh (+40 °C) |
| MTBF | 641 kh (+40 °C, SN29500) |
| Nominal value output current 1 | 10 A |
| Nominal value output voltage 1 | 24 V |
| Operating Temperature | -25 °C |
| Output voltage stabilized | True |
| Power Factor | 0.97 typical |
| Power losses | 13.4 W typical |
| Power output | 240 W |
| Power reserves | 20 % |
| Rail mounting possible | True |
| Rated supply voltage at AC 50 Hz | 100 V |
| Rated supply voltage at AC 60 Hz | 100 V |
| Rated supply voltage at DC | 110 V |
| Secondary voltage adjustable | False |
| Stabilized | True |
| Standard Warranty Duration | 1 year |
| Type of electric connection | Spring clA connection |
| UPC | 194033313838 |
| Voltage type of supply voltage | AC/DC |
| Wall mounting possible | True |
| Weight | 600 g |
| Width | 39 mm mm |
Frequently Asked Questions
How do I get pricing for 1606-XLE240ERL?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 1606-XLE240ERL?
1606-XLE240ERL is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 1606-XLE240ERL?
Key specifications include Adjustment range: Fixed; DC OK relay contact: True; Degree of protection (IP): IP20; Depth: 117 mm. The full specification table on this page lists every published attribute for this part.
How quickly can 1606-XLE240ERL ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
