Allen-Bradley 1494U-J30-CR-NO-PC-S — 1494U Disconnect Switch Rod or Cable Operated
Allen-Bradley 1494U-J30-CR-NO-PC-S - 1494U Disconnect Switch Rod or Cable Operated - Width: 6.81 in mm; Height: 8.58 in mm; Relative Humidity: 90% @ 20°C (68 °F) and 50% @ 40°C (104 °F) per IEC 947-1.
In our catalog, the 1494U-J30-CR-NO-PC-S from Allen-Bradley is listed under the 1494U Disconnect Switch Rod or Cable Operated category. The manufacturer's published data for this part number specifies Width: 6.81 in mm and Height: 8.58 in mm.
Switches, mechanisms and accessory kits: Zinc-plated Steel, RoHS compliant finish
Published specifications for this part include Relative Humidity: 90% @ 20°C (68 °F) and 50% @ 40°C (104 °F) per IEC 947-1; Ambient temperature: Storage: -40...65 °C (-40...149 °F); Degree of protection: Operating handles: Stainless Steel Type 4, 4X; Depth: 3.63 in; Type of electrical connection of main circuit: Screw connection; Altitude: 2000 m (6562 ft) per IEC 947-1; Auxiliary contact electrical ratings: AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 17V @ 5mA minimum per IEC; Conductor size: Single Port copper lug: 16 AWG @ copper conductor; Device construction: Built-in device fixed built-in technique; Dielectric strength: 2200V @ 1min; Electrical interlock ratings: Standard contact 2 NO: 10A @ 250V AC, 0.3A @ 250V DC per NEMA/EEMAC; Max. rated operation voltage Ue AC: 600 V. See the Specifications tab on this page for the full technical table.
| Altitude | 2000 m (6562 ft) per IEC 947-1 |
|---|---|
| Ambient temperature | Storage: -40...65 °C (-40...149 °F) |
| Auxiliary contact electrical ratings | AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 17V @ 5mA minimum per IEC |
| Conductor size | Single Port copper lug: 16 AWG @ copper conductor |
| Connection type | Switch body : glass-filled thermoplastic |
| Continuous current rating | 30 A |
| Degree of protection | Operating handles: Stainless Steel Type 4, 4X |
| Depth | 3.63 in |
| Device construction | Built-in device fixed built-in technique |
| Dielectric strength | 2200V @ 1min |
| Efficiency | -20 |
| Electrical interlock ratings | Standard contact 2 NO: 10A @ 250V AC, 0.3A @ 250V DC per NEMA/EEMAC |
| Estimated Lead Time | 29 days |
| Factory option | Threaded rod (19 in max.) |
| Flicker | 10A @ 250V AC, 0.3A @ 250V DC per NEMA/EEMAC |
| Fuse block option | 15 kW @ 500...600V AC, 3-phase, 50 Hz |
| Height | 8.58 in mm |
| Hold-up time | -40 |
| Hp rating, max | 7.5Hp @ 230V AC, 3-phase, 60 Hz per UL and CSA |
| Individual harmonics (DC-127th) | 15Hp @ 600V DC per UL and CSA |
| Interharmonics | AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 17V @ 5mA min per IEC |
| Interlockable | True |
| KW rating, max | 5.5 kW @ 220...240V AC, 3-phase, 50 Hz per IEC (AC23) |
| LED status | 10000 |
| Level-5 lens color | 2000 m per IEC 947-1 |
| Material | Switches, mechanisms and accessory kits: Zinc-plated Steel, RoHS compliant finish |
| Max. rated operation voltage Ue AC | 600 V |
| Mechanical life operations | 10000 |
| Motor drive optional | False |
| NEMA rating designation | 30A @ 250/600V DC |
| Number of auxiliary contacts as normally open contact | 1 |
| Number of poles | 3 |
| Number of switches | 1 |
| Operating distance | 2200V @ 1min |
| Operating handle style | Knife switch style handle |
| Operational range | 200000A @ 600V AC : with class J or class R fuses |
| Power losses | 1.5 |
| Rated input current | Lug to terminal : 20 in-lb |
| Rated output current | 600V @ 30A switch, 30 A type J fuse clips |
| Rated permanent current Iu | 30 A |
| Recommended torque | Switch side: 45 in-lb |
| Relative Humidity | 90% @ 20°C (68 °F) and 50% @ 40°C (104 °F) per IEC 947-1 |
| Short circuit withstand capability | 200000A @ 600V AC, with class J or class R fuses |
| Special family function | 6 |
| Special product function | Knife switch style handle |
| Spot size | 90% @ 20°C (68 °F) and 50% @ 40°C (104 °F) per IEC 947-1 |
| Standard Warranty Duration | 1 year |
| Sub group | -20 |
| Switch and fuse rating (fusing) | 600V @ 30A switch, 30 A Type J fuse clips |
| Switching frequency, max | 6 ops/m |
| Temperature, max | Stainless steel handle |
| Transient detect | AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 5V @ 1mA min per IEC |
| Type of control element | Long turning handle |
| Type of electrical connection of main circuit | Screw connection |
| UPC | 887172849435 |
| Version as main switch | True |
| Voltage release optional | False |
| Width | 6.81 in mm |
| With pre-assembled cabling | False |
