Allen-Bradley 1408-EM3A-ENT

Name: Allen-Bradley 1408-EM3A-ENT
Brand: Allen-Bradley
SKU: 1408-EM3A-ENT

Brand: Allen-Bradley SKU: 1408-EM3A-ENT Mfr Part #: 1408-EM3A-ENT

Ships Same Day* Worldwide Shipping

Allen-Bradley 1408-EM3A-ENT - Drives & Motors category.

In our catalog, the 1408-EM3A-ENT from Allen-Bradley is listed under the Drives & Motors category.

Specification data for this part number is available on request from our order desk.

Accuracy	1.00%
Alarm log	True
Alarms	True
Ampere meter	True
Apparent power (kVA)	True
Apparent power consumption (kVAh)	True
Apparent power demand (kVA)	True
Blind power meter	True
CIP energy object	True
Communications	EtherNet/IP
Configurable via webpage	True
Configuration lock wiring terminals	Wire together to help prevent configuration changes
Control power	85…264V AC, 47…63 Hz 125…250V DC 4VA maximum
Control power and ground wiring terminals	120…240V AC, 50…60 Hz
Current	True
Current sense inputs: I1, I2, I3	Starting current : 5 mA
Current sensing wiring terminals	Nominal input current 5 A, Use current transformers (CTs) to connect to power system
Current unbalance	True
Demand power factor	True
Description	PowerMonitor 1000 energy, demand, and PowerMonitor with serial network communication
Dielectric withstand	UL61010, EN61010 pollution degree 2
Digital accuracy	Class1
Digital output	True
DIN rail clips	Top and bottom clips for mounting unit on DIN rail
Display (integrated LCD)	True
Effective power measurement device	True
Energy log	True
Energy management meter w/Ethernet	True
Estimated Lead Time	5 days
Frequency	Hz: Yes
Frequency meter	True
Frequency Rating	40-75Hz
Humidity	5...95% noncondensing
Interface	Webpage
KYZ output	80mA @ 240V AC / 300V DC (except BC3)
KYZ-output wiring terminals	DPDT solid-state relay for signaling use - not present on BC3 model
LCD	Unit configuration data display - not present on BC3 model
LCD interface buttons	Unit configuration data display navigation not present on BC3 model
Load factor log	True
Mac ID label	Aa:bb:cc:dd:ee:ff, used when assigning an IP address using DHCP, X, X, X
Metering Voltage	600VLL AC
Minimum/maximum log	True
Module and network status indicators	Module indicator GREEN: normal ops Alternating RED/GREEN: performing self-test RED (solid or blinking): initial power-up or failed self-test. network indicator GREEN: Ethernet connection established Blinking GREEN: Ethernet port looking for a connection RED: duplicate IP address detected.
Operating Temperature	-10 to 60 °C
Output	2 Digital Relays
Projected kVA demand	True
Projected kVAR demand	True
Projected kW demand	True
Pulse counter	True
Reactive power (kVAR)	True
Reactive power consumption (kVARh)	True
Reactive power demand (kVAR)	True
Real power (kW)	True
Real power consumption (kWh)	True
Real power demand (kW)	True
Serial port - three-pin RS-485 connector	All models include RS-485 serial communication that supports the following protocols and functions. DF1 half-duplex slave, DF1 full-duplex, Modbus RTU slave, Configuration by using terminal emulation software, DH-485.
Serial port status indicators	Tx indicator flashes yellow when data is being transmitted Rx indicator flashes yellow when data is being received
Shock	Operating : 30 G peak each axis
Standard Warranty Duration	1 year
Status inputs	Contact closure (internal 24V DC)(except BC3)
Storage Temperature	-40 to 85 °C
Terminal blocks	0.34…2.5 mm² (22 AWG), 75 °C (167 °F) min copper wire only recommended torque 0.8 N.m (7 in-lb)
Time of use log	True
True power factor	True
Unit status log	True
UPC	662074663545
Vibration	2.0 G @ 10…500 Hz
Voltage	True V
Voltage sense inputs: V1, V2, V3, max	Input current : 2 mA
Voltage sense inputs: V1, V2, V3, min	Input impedance : 5 MΩ
Voltage sensing wiring terminals	Direct connect up to 600V AC three-phase line-to-line, Maximum nominal line-to-ground voltage 347V, Use potential transformers (PTs) for higher voltages.
Voltage unbalance	True
Voltmeter	True

Frequently Asked Questions

How do I get pricing for 1408-EM3A-ENT?

KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.

Who manufactures the 1408-EM3A-ENT?

1408-EM3A-ENT is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.

What are the key specifications of 1408-EM3A-ENT?

Key specifications include Accuracy: 1.00%; Alarm log: True; Alarms: True; Ampere meter: True. The full specification table on this page lists every published attribute for this part.

How quickly can 1408-EM3A-ENT ship?

In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
