Weidmuller WDK 2.5 2D 1.A
Weidmuller 8014670000 - Fuse and component terminal blocks - Width: 5.1 mm mm; Height: 69 mm mm; Storage Temperature: -25 °C...55 °C.
This listing covers the Weidmuller 8014670000, a part number in the Fuse and component terminal blocks category. The manufacturer's published data for this part number specifies Width: 5.1 mm mm and Height: 69 mm mm.
Component terminal block, Screw connection, dark beige, 2.5 mm², 400 V, 400 V, Number of connections: 4, Number of levels: 2, TS 35
Published specifications for this part include Storage Temperature: -25 °C...55 °C; Nominal current: 0.5 A; Type of mounting: Snap-on; Ambient temperature: -50 °C…75 °C; Type: WDK 2.5 2D 1.A; Depth: 62.5 mm; Net weight: 12.35 g; Colour: dark beige; Display: Without LED; Rated voltage: 400 V; Stripping length: 10 mm; Blade Size: 0.6 x 3.5 mm. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -50 °C…75 °C |
|---|---|
| Basic material | Wemid |
| Blade Size | 0.6 x 3.5 mm |
| Certificate No. (UR) | E60693 |
| Clamping range, max. | 4 mm² |
| Clamping range, min. | 0.05 mm² |
| Clamping screw | M 2.5 |
| Colour | dark beige |
| Component 1 | Diode 1N 4007 |
| Component 2 | Diode 1N 4007 |
| Component current | 1 A |
| Component voltage | 1,000 V |
| Conductor size Factory wiring max. (UR) | 12 AWG |
| Conductor size Factory wiring min. (UR) | 22 AWG |
| Conductor size Field wiring max. (UR) | 12 AWG |
| Conductor size Field wiring min. (UR) | 22 AWG |
| Connection cross-section, stranded, max. | 4 mm² |
| Connection cross-section, stranded, min. | 1.5 mm² |
| Connection direction | on side |
| Continuous operating temp., max. | 120 °C |
| Continuous operating temp., min. | -50 °C |
| Current at maximum wires | 0.5 A |
| Current size B (UR) | 20 A |
| Current size C (UR) | 20 A |
| Depth | 62.5 mm |
| Depth (inches) | 2.461 inch |
| Depth including DIN rail | 63 mm |
| Display | Without LED |
| ECLASS 14.0 | 27-25-01-14 |
| ECLASS 15.0 | 27-25-01-14 |
| Element type | Diode |
| End cover plate required | Yes |
| ETIM 10.0 | EC000903 |
| ETIM 8.0 | EC000903 |
| ETIM 9.0 | EC000903 |
| Explosion-tested version | No |
| Gauge to IEC 60947-1 | A3 |
| GTIN (EAN) | 4008190037345 |
| Height | 69 mm mm |
| Height (inches) | 2.717 inch |
| Levels cross-connected internally | Yes |
| Mounting rail | TS 35 |
| N-function | No |
| Net weight | 12.35 g |
| Nominal current | 0.5 A |
| Number of clamping points per level | 2 |
| Number of connections | 4 |
| Number of levels | 2 |
| Number of potentials | 1 |
| Number of potentials per tier | 1 |
| Number of similar terminals | 1 |
| Open sides | right |
| Order No. | 8014670000 |
| PE connection | No |
| PE function | No |
| PEN function | No |
| Pollution severity | 3 |
| Power loss in accordance with IEC 60947-7-x | 0.77 W |
| Product information | Rated current 10 A only for the continuous currentbar. Components may reduce the rated current and the rated voltage. The permissible continuous operating temperature must be observed. The allowed continuous operating temperature must be observed |
| Qty. | 25 items |
| Rated cross-section | 2.5 mm² |
| Rated DC voltage | 400 V |
| Rated impulse withstand voltage | 6 kV |
| Rated voltage | 400 V |
| REACH SVHC | Lead 7439-92-1 |
| ROHS | Conform |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 7a |
| SCIP | a3090896-0f16-410d-aabb-617cfb571002 |
| Standards | IEC 60947-7-1 |
| Storage Temperature | -25 °C...55 °C |
| Stripping length | 10 mm |
| Tightening torque (max) | 0.6 Nm Nm |
| Tightening torque, min. | 0.4 Nm |
| TS 35 offset | 35.5 mm |
| Type | WDK 2.5 2D 1.A |
| Type of connection | Screw connection |
| Type of connection 2 | Screw connection |
| Type of mounting | Snap-on |
| UL 94 flammability rating | V-0 |
| Version | Component terminal block, Screw connection, dark beige, 2.5 mm², 400 V, 400 V, Number of connections: 4, Number of levels: 2, TS 35 |
| Voltage size B (UR) | 300 V |
| Voltage size C (UR) | 300 V |
| Volume resistance according to IEC 60947-7-x | 1.33 mΩ |
| Width | 5.1 mm mm |
| Width (inches) | 0.201 inch |
| Wire connection cross section AWG, max. | AWG 12 |
| Wire connection cross section AWG, min. | AWG 26 |
| Wire connection cross section, finely stranded, max. | 4 mm² |
| Wire connection cross section, finely stranded, min. | 0.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max. | 2.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min. | 0.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max. | 2.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min. | 0.13 mm² |
| Wire connection cross-section, solid core, max. | 4 mm² |
| Wire connection cross-section, solid core, min. | 0.5 mm² |
