Weidmuller ZDU 1.5/2X2AN
Weidmuller 1826970000 - Feed-through and PE terminal Blocks - Width: 3.5 mm mm; Height: 75.5 mm mm; Storage Temperature: -25 °C...55 °C.
Weidmuller 1826970000 is a Feed-through and PE terminal Blocks catalog item from Weidmuller. The manufacturer's published data for this part number specifies Width: 3.5 mm mm and Height: 75.5 mm mm.
Feed-through terminal, Tension-clamp connection, 1.5 mm², 500 V, 17.5 A, dark beige
Key manufacturer data on file for this item includes Storage Temperature: -25 °C...55 °C; Nominal current: 17.5 A; Type of mounting: Snap-on; Ambient temperature: -50 °C…75 °C; Type: ZDU 1.5/2X2AN; Depth: 36.5 mm; Net weight: 6.49 g; Colour: dark beige; Rated voltage: 500 V; Stripping length: 10 mm; Blade Size: 0.4 x 2.0 mm; ROHS: Conform. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -50 °C…75 °C |
|---|---|
| Basic material | Wemid |
| Blade Size | 0.4 x 2.0 mm |
| Clamping range, max. | 1.5 mm² |
| Clamping range, min. | 0.05 mm² |
| Colour | dark beige |
| Connection cross-section, finely stranded, min. | 0.05 mm² |
| Connection cross-section, stranded, max. | 1.5 mm² |
| Connection cross-section, stranded, min. | 0.05 mm² |
| Connection direction | top |
| Connection type, additional connection | Tension-clamp connection |
| Continuous operating temp., max. | 120 °C |
| Continuous operating temp., min. | -50 °C |
| Current at maximum wires | 17.5 A |
| Depth | 36.5 mm |
| Depth (inches) | 1.437 inch |
| Depth including DIN rail | 37 mm |
| ECLASS 14.0 | 27-25-01-01 |
| ECLASS 15.0 | 27-25-01-01 |
| End cover plate required | Yes |
| ETIM 10.0 | EC000897 |
| ETIM 8.0 | EC000897 |
| ETIM 9.0 | EC000897 |
| Explosion-tested version | No |
| Gauge to IEC 60947-1 | B1 |
| GTIN (EAN) | 4032248425297 |
| Height | 75.5 mm mm |
| Height (inches) | 2.972 inch |
| Installation advice | Direct mounting |
| Levels cross-connected internally | No |
| Mounting rail | TS 35 |
| Net weight | 6.49 g |
| Nominal current | 17.5 A |
| Number of clamping points per level | 4 |
| Number of connections | 4 |
| Number of levels | 1 |
| Number of potentials | 1 |
| Number of potentials per tier | 2 |
| Open sides | right |
| Order No. | 1826970000 |
| PE connection | No |
| Pollution severity | 3 |
| Power loss in accordance with IEC 60947-7-x | 0.56 W |
| Qty. | 100 items |
| Rated cross-section | 1.5 mm² |
| Rated DC voltage | 500 V |
| Rated impulse withstand voltage | 6 kV |
| Rated voltage | 500 V |
| REACH SVHC | No SVHC above 0.1 wt% |
| ROHS | Conform |
| RoHS Compliance Status | Compliant without exemption |
| Standards | IEC 60947-7-1 |
| Storage Temperature | -25 °C...55 °C |
| Stripping length | 10 mm |
| Twin wire-end ferrules, max. | 0.75 mm² |
| Twin wire-end ferrules, min. | 0.5 mm² |
| Type | ZDU 1.5/2X2AN |
| Type of connection | Tension-clamp connection |
| Type of mounting | Snap-on |
| UL 94 flammability rating | V-0 |
| Version | Feed-through terminal, Tension-clamp connection, 1.5 mm², 500 V, 17.5 A, dark beige |
| Volume resistance according to IEC 60947-7-x | 1.83 mΩ |
| Width | 3.5 mm mm |
| Width (inches) | 0.138 inch |
| Wire connection cross section AWG, max. | AWG 18 |
| Wire connection cross section AWG, min. | AWG 28 |
| Wire connection cross section, finely stranded, max. | 1.5 mm² |
| Wire connection cross section, finely stranded, min. | 0.05 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max. | 1.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min. | 0.05 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max. | 1.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min. | 0.05 mm² |
| Wire connection cross-section, solid core, max. | 1.5 mm² |
| Wire connection cross-section, solid core, min. | 0.05 mm² |
