Compact evaluation unit for speed monitoring - DI6004
IFM DI6004 - Compact evaluation unit for speed monitoring - Weight: 119.35; Ambient temperature: -25...85; Connector: 1 x M12; coding: A; Contacts: 4, gold-plated.
In our catalog, the DI6004 from IFM is listed under the Compact evaluation unit for speed monitoring category. The manufacturer's published data for this part number specifies Weight: 119.35 and Ambient temperature: -25...85.
housing: stainless steel (1.4404 / 316L); sensing face: PBT; LED window: PEI; lock nuts: stainless steel (1.4404 / 316L)
The specification set recorded for this part number covers Connector: 1 x M12; coding: A; Contacts: 4, gold-plated; Tightening torque: 35; Protection class: II; Dimensions: M18 x 1 / L = 75; Application: evaluation of rotating and linear movements with regard to underspeed; blocking; Output signal: switching signal; Product type: Compact evaluation unit for speed monitoring; Mounting: non-flush mountable; Communication interface: IO-Link; Measuring range: 1...32000; Operating voltage: 10...30 DC; Current consumption: < 15. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -25...85 |
|---|---|
| Application | evaluation of rotating and linear movements with regard to underspeed; blocking |
| Communication interface | IO-Link |
| Connector | 1 x M12; coding: A; Contacts: 4, gold-plated |
| Correction factor | stainless steel: 0.7 / brass: 0.5 / aluminum: 0.5 / copper: 0.4 |
| Current consumption | < 15 |
| Dimensions | M18 x 1 / L = 75 |
| Electrical design | PNP/NPN; (configurable) |
| Housing | Threaded type |
| Hysteresis | 10 |
| IO-Link functions (acyclical) | switch-on cycle counter; operating hours counter; internal temperature; application specific tag |
| IO-Link revision | 1.1 |
| Key Features | Reliable non-contact monitoring of the rotational speed with regard to underspeed; 2 in 1: speed sensor and evaluation in one compact housing; Easy setting of the switch point via teach button or IO-Link; Reduced installation complexity |
| Material | housing: stainless steel (1.4404 / 316L); sensing face: PBT; LED window: PEI; lock nuts: stainless steel (1.4404 / 316L) |
| Max. damping frequency | 60000 |
| Max. voltage drop switching output DC | 2.5 |
| Measuring principle | inductive |
| Measuring range | 1...32000 |
| Min. process cycle time | 3.7 |
| Mounting | non-flush mountable |
| MTTF | 467 |
| Operating voltage | 10...30 DC |
| Output function | normally open / closed; (configurable) |
| Output signal | switching signal |
| Overload protection | yes |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 250 |
| Product type | Compact evaluation unit for speed monitoring |
| Protection | IP 65; IP 66; IP 67; IP 68; IP 69K |
| Protection class | II |
| Pulse output | external evaluation of the damping pulses |
| Repeatability IO-Link | 1; (of the final value of the measuring range) |
| Required master port class | A |
| Reverse polarity protection | yes |
| SDCI standard | IEC 61131-9 |
| Sensing range | 12 |
| Setting range | 3...24000 |
| Short circuit protection | yes |
| SIO mode | yes |
| Special Feature | gold-plated contacts |
| Specification Summary | Speed monitor; M18 x 1 / L = 75 mm; PNP/NPN; (configurable); normally open / closed; (configurable); 12 mm; non-flush mountable; IO-Link; Connector |
| Start-up delay | 0...15; (In steps of: 1 s; default: 10 s) |
| Switching frequency DC | < 500 |
| Temperature drift | ± 10 %; (of the final value of the measuring range) |
| Thread designation | M18 x 1 |
| Tightening torque | 35 |
| Transmission type | COM2 (38,4 kBaud) |
| Weight | 119.35 |
Frequently Asked Questions
How do I get pricing for DI6004?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the DI6004?
DI6004 is a IFM part. KKM Solutions sources IFM components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of DI6004?
Key specifications include Ambient temperature: -25...85; Application: evaluation of rotating and linear movements with regard to underspeed; blocking; Communication interface: IO-Link; Connector: 1 x M12; coding: A; Contacts: 4, gold-plated. The full specification table on this page lists every published attribute for this part.
How quickly can DI6004 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
Related Products
IFM Compact evaluation unit for speed monitoring - DI6005
