Endress+Hauser iTHERM ModuLine TM401Hygienic modular thermometer
Endress+Hauser TM401 - Temperature - Accuracy: class A acc. to IEC 60751; Response time: depending on configuration; Measuring principle: Resistance Temperature Detector.
Endress+Hauser TM401 is a Temperature catalog item from Endress+Hauser. The manufacturer's published data for this part number specifies Accuracy: class A acc. to IEC 60751 and Response time: depending on configuration.
compression fitting triclamp microclamp clamp connections acc. to ISO2852 Ingold G3/4" Liquiphant G1" Liquiphant Varivent SMS 1147 screwed pipe joint acc. to DIN 11851
Published specifications for this part include Measuring principle: Resistance Temperature Detector; Certification: SIL (transmitter only); Thermowell / protection tube: without (not intended to use with thermowell); Insert / probe: without exchangeable insert; Outer diameter protection tube / Insert: 6,0 mm (0,24") 8,0 mm (0,31"); Max. immersion length on request: up to 400 mm (15,75"); Material protection tube/ thermowell: 316L; Tip shape: straight reduced; Surface roughness Ra: 0,76 μm (30 μin) 0,38 μm (15 μin); Operating temperature range: PT100: -50 °C … 200 °C (-58 °F … 392 °F); Max. process pressure (static): at 20 °C: 40 bar (580 psi); Integration head transmitter: yes (4 ... 20 mA, HART). See the Specifications tab on this page for the full technical table.
| Accuracy | class A acc. to IEC 60751 |
|---|---|
| Certification | SIL (transmitter only) |
| Characteristic / Application | metric style hygienic applications aseptic applications hygienic process connections with neck |
| Insert / probe | without exchangeable insert |
| Integration head transmitter | yes (4 ... 20 mA, HART) |
| Material protection tube/ thermowell | 316L |
| Max. immersion length on request | up to 400 mm (15,75") |
| Max. process pressure (static) | at 20 °C: 40 bar (580 psi) |
| Measuring principle | Resistance Temperature Detector |
| Operating temperature range | PT100: -50 °C … 200 °C (-58 °F … 392 °F) |
| Outer diameter protection tube / Insert | 6,0 mm (0,24") 8,0 mm (0,31") |
| Process Connection | compression fitting triclamp microclamp clamp connections acc. to ISO2852 Ingold G3/4" Liquiphant G1" Liquiphant Varivent SMS 1147 screwed pipe joint acc. to DIN 11851 |
| Response time | depending on configuration |
| Surface roughness Ra | 0,76 μm (30 μin) 0,38 μm (15 μin) |
| Thermowell / protection tube | without (not intended to use with thermowell) |
| Tip shape | straight reduced |
Frequently Asked Questions
How do I get pricing for TM401?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the TM401?
TM401 is a Endress+Hauser part. KKM Solutions sources Endress+Hauser components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of TM401?
Key specifications include Accuracy: class A acc. to IEC 60751; Certification: SIL (transmitter only); Characteristic / Application: metric style hygienic applications aseptic applications hygienic process connections with neck; Insert / probe: without exchangeable insert. The full specification table on this page lists every published attribute for this part.
How quickly can TM401 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
