Beckhoff EP4174-0002 — EtherCAT Box
The EP4174-0002 EtherCAT Box has four analog outputs which can be individually parameterized, so that they generate signals either in the -10…+10 V or the 0/4…20 mA range. The voltage or output current is supplied to the process level with a resolution
| Actuator supply | from the auxiliary voltage UP |
|---|---|
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Conversion time | ~ 40 µs |
| Current consumption from US | 120 mA |
| Electrical isolation | 500 V |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Ex marking | ATEX: II 3 G Ex ec IIC T4 Gc II 3 D Ex tc IIIC T135 °C Dc IECEx: Ex ec IIC T4 Gc Ex tc IIIC T135 °C Dc |
| Load | > 5 kΩ | < 500 Ω |
| Measurement error/uncertainty | < 0.1% (relative to full scale value) |
| Nominal Voltage | 24 V DC (-15%/+20%) |
| Number Of Channels | 4 analog outputs |
| Operating Temperature | -25…+60°C |
| Output connections | M12 x 1, 5-pin, a-coded |
| Output error | < 0.1% (relative to end value) |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Protocol | EtherCAT |
| Resolution | 16 bit |
| Signal type | -10/0…+10 V | -20/0/4…+20 mA, parameterizable per channel |
| Special Features | current or voltage parameterizable per channel |
| Storage Temperature | -40…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Weight | approx. 165 g |
Frequently Asked Questions
How do I get pricing for EP4174-0002?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EP4174-0002?
EP4174-0002 is a Beckhoff part. KKM Solutions sources Beckhoff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of EP4174-0002?
Key specifications include Actuator supply: from the auxiliary voltage UP; Approvals/markings: CE, CCC, UL, ATEX, IECEx; Bus interface: 2 x M8 socket, 4-pin, a-coded, shielded; Conversion time: ~ 40 µs. The full specification table on this page lists every published attribute for this part.
How quickly can EP4174-0002 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
