Weidmuller A3C 16 PE
Weidmuller 2494020000 - Feed-through and PE terminal Blocks - Width: 12 mm mm; Height: 102 mm mm; Storage Temperature: -25 °C...55 °C.
The 2494020000 from Weidmuller is listed under Feed-through and PE terminal Blocks in our catalog. The manufacturer's published data for this part number specifies Width: 12 mm mm and Height: 102 mm mm.
Published specifications for this part include Storage Temperature: -25 °C...55 °C; Type of mounting: TS 35; Ambient temperature: -60 °C…85 °C; Type: A3C 16 PE; Depth: 51.5 mm; Net weight: 60.512 g; Colour: Green/yellow; Rated voltage: 1,000 V; Stripping length: 18 mm; Version: PE terminal, PUSH IN, 16 mm², 1000 V, Green/yellow; Blade Size: 1.0 x 5.5 mm; ROHS: Conform. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -60 °C…85 °C |
|---|---|
| Basic material | Wemid |
| Blade Size | 1.0 x 5.5 mm |
| Certificate No. (ATEX) | TUEV16ATEX7909U |
| Certificate No. (CSA) | 200039-70089609 |
| Certificate No. (cURus) | E60693 |
| Certificate No. (cURusEX) | E184763 |
| Certificate No. (IECEX) | IECEXTUR16.0036U |
| Clamping range, max. | 25 mm² |
| Clamping range, min. | 0.5 mm² |
| Colour | Green/yellow |
| Colour of operational elements | orange |
| Conductor size Factory wiring max. (cURus) | 6 AWG |
| Conductor size Factory wiring min. (cURus) | 18 AWG |
| Conductor size Field wiring max. (cURus) | 6 AWG |
| Conductor size Field wiring min. (cURus) | 18 AWG |
| Connection cross-section, finely stranded, min. | 0.5 mm² |
| Connection cross-section, stranded, max. | 25 mm² |
| Connection cross-section, stranded, min. | 0.5 mm² |
| Connection direction | top |
| Connection type, additional connection | PUSH IN |
| Continuous operating temp., max. | 130 °C |
| Continuous operating temp., min. | -60 °C |
| Depth | 51.5 mm |
| Depth (inches) | 2.028 inch |
| Depth including DIN rail | 52.5 mm |
| ECLASS 14.0 | 27-25-01-03 |
| ECLASS 15.0 | 27-25-01-03 |
| End cover plate required | Yes |
| ETIM 10.0 | EC000901 |
| ETIM 8.0 | EC000901 |
| ETIM 9.0 | EC000901 |
| Explosion-tested version | Yes |
| Gauge to IEC 60947-1 | A6 |
| GTIN (EAN) | 4050118503883 |
| Height | 102 mm mm |
| Height (inches) | 4.016 inch |
| Installation advice | Rail |
| Mounting rail | TS 35 |
| Net weight | 60.512 g |
| Number of clamping points per level | 3 |
| Number of connections | 3 |
| Number of levels | 1 |
| Number of potentials | 1 |
| Number of potentials per tier | 1 |
| Open sides | right |
| Order No. | 2494020000 |
| PE connection | Yes |
| PE function | Yes |
| PEN function | Yes |
| Pollution severity | 3 |
| Power loss in accordance with IEC 60947-7-x | 0 W |
| Qty. | 20 items |
| Rated cross-section | 16 mm² |
| Rated DC voltage | 1,000 V |
| Rated impulse withstand voltage | 8 kV |
| Rated impulse withstand voltage to adjacent terminal | 8 kV |
| Rated voltage | 1,000 V |
| Rated voltage to adjoining terminal | 1,000 V |
| REACH SVHC | No SVHC above 0.1 wt% |
| ROHS | Conform |
| RoHS Compliance Status | Compliant without exemption |
| Snap-on | No |
| Standards | IEC 60947-7-2 |
| Storage Temperature | -25 °C...55 °C |
| Stripping length | 18 mm |
| Surge voltage category | III |
| Twin wire-end ferrules, max. | 6 mm² |
| Twin wire-end ferrules, min. | 0.75 mm² |
| Type | A3C 16 PE |
| Type of connection | PUSH IN |
| Type of fixing | Snap-on |
| Type of mounting | TS 35 |
| UL 94 flammability rating | V-0 |
| Version | PE terminal, PUSH IN, 16 mm², 1000 V, Green/yellow |
| Voltage size B (CSA) | 600 V |
| Voltage size B (cURus) | 600 V |
| Voltage size C (CSA) | 600 V |
| Voltage size C (cURus) | 600 V |
| Voltage size D (CSA) | 600 V |
| Voltage size D (cURus) | 600 V |
| Volume resistance according to IEC 60947-7-x | 0.42 mΩ |
| Width | 12 mm mm |
| Width (inches) | 0.472 inch |
| Wire connection cross section AWG, max. | AWG 4 |
| Wire connection cross section AWG, min. | AWG 18 |
| Wire connection cross section, finely stranded, max. | 25 mm² |
| Wire connection cross section, finely stranded, min. | 0.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max. | 16 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min. | 0.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max. | 16 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min. | 0.5 mm² |
| Wire connection cross-section, solid core, max. | 16 mm² |
| Wire connection cross-section, solid core, min. | 0.5 mm² |
| Wire cross section max. (ATEX) | 16 mm² |
| Wire cross section max. (CSA) | 6 AWG |
| Wire cross section max. (IECEX) | 16 mm² |
| Wire cross section min. (CSA) | 18 AWG |
| With snap-in pegs | No |
