US Motors S20P2G 20 HP 4-Pole TEFC 3-Phase 1775 RPM Electric Motor
| Ambient | 40 |
|---|---|
| Assembly Position | F1 |
| Breakdown Torque | 307 |
| Breakdown Torque Uom | PERCENT OF FLT |
| Frme | 256 |
| Full Load Amps Primary | 19.4 |
| Hertz | 60 |
| Horsepower | 20 HP |
| Insulation Class | F |
| Kilowatts | 14.9 |
| Kva Code Letter | J |
| Locked Rotor Amps | 146 |
| Locked Rotor Torque Uom | PERCENT OF FLT |
| Locked-Rotor Torque | 305 |
| Motor Enclosure | TEFC |
| Motor Type | SE |
| Mounting | HORZ-FOOTED |
| Nema Nominal Efficiency | 93 |
| Number Speeds | 1 |
| Opposite End Bearing | 6207-2Z-J/C3 |
| Phasetype | 3_PHASE |
| Poles | 4 |
| Rotation | DUAL |
| Service Factor | 1.15 |
| Service Factor Amps Primary | 22 |
| Shaft Code | T |
| Shaft End Bearing | 6309-2Z-J/C3 |
| Shipping Weight | 230 |
| Speed | 1775 RPM |
| Startcapmfd | N\A |
| Volts | 575 |
| Volts Primary | 575 |
