US Motors HD200P2GS 200 HP 4-Pole TEFC 3-Phase 1785 RPM Electric Motor
| Ambient | 40 |
|---|---|
| Assembly Position | F1 |
| Breakdown Torque | 263 |
| Breakdown Torque Uom | PERCENT OF FLT |
| Frme | 447 |
| Full Load Amps Primary | 181 |
| Hertz | 60 |
| Horsepower | 200 HP |
| Insulation Class | F |
| Kilowatts | 149.1 |
| Kva Code Letter | F |
| Locked Rotor Amps | 1174.8 |
| Locked Rotor Torque Uom | PERCENT OF FLT |
| Locked-Rotor Torque | 132 |
| Motor Enclosure | TEFC |
| Motor Type | CTE |
| Mounting | HORZ-FOOTED |
| Nema Nominal Efficiency | 95.8 |
| Number Speeds | 1 |
| Opposite End Bearing | 6313-J/C3 |
| Phasetype | 3_PHASE |
| Poles | 4 |
| Rotation | DUAL |
| Service Factor | 1.15 |
| Service Factor Amps Primary | 208 |
| Shaft Code | TS |
| Shaft End Bearing | 6313-J/C3 |
| Shipping Weight | 1760 |
| Speed | 1785 RPM |
| Startcapmfd | N\A |
| Volts | 575 |
| Volts Primary | 575 |
